HF-YD7 functional full hydraulic impact hammer pile driver for foundation construction
HF-YD types of full hydraulic functonal hammer is our company launch a type of piling machinery in 2010. According to hammer weight, we have HF-YD5, HF-YD6 and HF-YD7 types of piling driver il cylinder can automatically adjust the oil cylinder trip and realize thump and tip-tap. When dismantle hydraulic piling the hammer and replace hydraulic power head, pressurization cylinder, scaleable Kelly bar and broach, it will get full hydraulic rotating drill of 65m-deep drilling.
Diameter |
500mm |
|
Max drilling depth |
4 joints |
—————— |
5 joints |
—————— |
|
Overall measurement |
Working dimension |
8042X3600X21250(mm) |
Transport dimension |
16460X2800X3300 (mm) |
|
Rotary drive torque |
—————— |
|
Rotary drive speed |
—————— |
|
Crowd cylinder |
Max push |
—————— |
Max pull |
—————— |
|
Max stroke |
—————— |
|
Main winch |
Max line pull |
140kN |
Max line speed |
70m/min |
|
Auxiliary winch |
Max line pull |
60kN |
Max line speed |
60m/min |
|
Engine |
Rated power |
133kW/2100 |
Type |
Cummins 6BTA5.9-C178 |
|
Electronic management system |
Long distance monitor system |
Available |
Drilling record system |
Available |
|
On car printer |
Available |
|
Hydraulic system pressure |
30mpa |
|
Chassis |
Chassis modality |
telescopic |
Max travel speed |
2.5km/h |
|
Min ground clearance |
330mm |
|
Track width |
800mm |
|
Mast inclination |
Forward / backward |
90° |
Left / right |
±3° |
|
Hammer weight |
7000kg |
|
Hammer stroke |
500-1500mm |
|
Impact frequency |
30time/min |
|
Max impact force |
105kN·m |
|
Whole machine weight |
47000kg |
|
