reliable performance HF-6A concrete core drilling machine
- 50 Set / Sets per Month
- Tianjin
- China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
- 100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
- HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
- 50m Depth Core Drilling Rig Portable Diamond in Mountain
- TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
- 1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
Condition: | New | Type: | Core Drilling Rig | Place of Origin: | Henan, China |
Brand Name: | Hanfa | Model Number: | HF-6A | Usage: | Water Well |
Dimension(L*W*H): | 9.30*2.50*3.10m | Weight: | 9500kg | Warranty: | one year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
HF-6A concrete core drilling machine1multifunction
2for various stratum
3high pore forming efficiency
4good pile formation
reliable performance HF-6A concrete core drilling machine
Main features
1. HF-6A is multifunctional type, mainly used for water well drilling, borehole drilling and piling foundation,etc.
2. it can adapt various stratum: soil, sand, clay, gravel, rock, etc
3. stable performance, with high pore forming efficiency and good pile formation quality.
4. can drill 200-300m depth with hole diameter 500mm (20" inches); drill 300-400m depth with hole diameter 600mm (24" inches)
Techinical paraments
Mechanical features | Specifications | |
Dimensions(M) | 9.30*2.50*3.10 | |
Transport dimensions(M) | 9.30*2.28*2.80 | |
Weight(kg) | 9500 | |
Drilling diameter(mm) | 300-1800 | |
Drilling depth(M) | 300(when dia. Is 600mm) | |
Max.Weight of drill bit(kg) | 5000 | |
Impact stroke(mm) | Max.850,Min.700 | |
Rate of impact(time/min) | 38-42 | |
Electric motor | Model YL280M2-6,55KW 980R/Min | |
Height of mast (M) | Single bar8.5-9.5m; Double bar12.5m | |
Load capacity of mast(kg) | 50000 | |
Hauling speed(km/h) | 30 | |
Lifting capacity of Hoist(N) | Front hoist | 20096 |
Back hoist | 68357 | |
Steel wire rope of coiling block(M) | Front coiling block | 6×37-φ18 200-250(Left turning) |
Back coiling block | 6×19s+IWRC 200-300(Left turning) | |
Wheel | Tire size | 7.50-20 |
Steel ring size | 20×7 |
If you want to learn more details, please contact us freely, we will try our best to work for you.
