Home > Products > DTH Drilling Rig > most popular on the market!!perfect drill rig,high efficent!!! HF100Y Mining DTH Drilling Rig
most popular on the market!!perfect drill rig,high efficent!!! HF100Y Mining DTH Drilling Rig
Negotiable
/ Set
1 Set(Min.Order)
- 20 Set / Sets per Month
- Qingdao
You May Like
-
most popular on the market!!perfect drill rig,high efficent!!! HF100Y Mining DTH Drilling Rig
-
DTH rock drilling! hot selling! HF138Y down the hole drilling equipment
-
DTH rock drilling! hot selling! HF138Y down the hole drilling machine
-
DTH rock drilling! hot selling! HF138Y down the hole drilling rig
-
DTH rock drilling! hot selling! HF138Y open mines drilling equipment
-
DTH rock drilling! hot selling! HF138Y open mines drilling rig
Product Details
| Condition | New | Type | Other, Down the hole drilling rig | |
| Power Type | Diesel | Brand Name | Hanfa | |
| Model Number | HF100Y | Usage | Water Well | |
| Power(W) | 18.6KW | Dimension(L*W*H) | 4100*2030*2020 | |
| Weight | 2600KG | Certification | ISO | |
| Warranty | 12Months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
most popular on the market!!perfect drill rig,high efficent!!! HF100Y Mining DTH Drilling RigHF100Y Mining DTH Drilling Rig
1
HF100Y Mining DTH Drilling Rig
I. Application
HF100Y DTH drilling rig can be used for urban construction, railway, highway, river, hydroelectric project and other projects in the rock drilling anchor holes, blast hole, bolt holes, blow holes, grouting hole, etc. It could drill hard rock with rock hardness f = 8-16.
II. Features
1. Caterpillar type, easy to transport.
2. High mechanical efficiency, low cost and stable performance.
3. Easy to operate, needing little experience to operate.
4. Economical and reasonable price.
| Main Machine Technical Parameter | |
| Model | HF100Y |
| Borehole diameter | 90-130mm |
| Rock type | Rock, hard rock, f=8-16 |
| Bore depth | 30m |
| Air pressure | 0.7-1.0Mpa |
| Air consumption | 7-15m³ /min |
| Flush-out frequency | 840 r/min |
| Gradeability | 30° |
| Travel speed | 2km/h |
| Pitch angle of carriage | up and down 10° |
| Tilt angle of carriage | left 35° right 10° |
| Length compensation of carriage | 900m |
| Engine | |
| Oil | diesel |
| Power | 18.6KW (25HP) |
| Weight | 2.6T |
