Drilling Rig

Drilling Rig thumbnail-1
Drilling Rig photo-1
US$ 100,000 - 500,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Brand Name:
XCMG
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Brand Name XCMG
Model Number XR120
Usage Other, base of road

Specifications

drilling rig, with cummins engine, 138kw~298kw, 40m~88m drilling depth.

Main Technical Data of XR Series Multi-functional Combined Rotary Drilling Rig:
Model   XR120 XR160 XR200 XR220 XR250 XR280
Engine Model CUMMINS 6CTAA8.3-C185 CUMMINS 6CTAA8.3-C240 CUMMINS M11-C330 CUMMINS M11-C330 CUMMINS QSM11-C400 CUMMINS QSM11-C400
Rated power 138KW 177KW 246KW/2100rpm 246KW/2100rpm 298KW/2050rpm 298KW/2050rpm
Rotary drive Max. output torque 120KN·M 160KN·M 200KN·M 220KN·M 250KN·M 280KN·M
Rotary speed 8~26r/min 8~26r/min 7~22r/min 7~22r/min 7~22r/min 7~22r/min
Max. drilling diameter With casing 1500mm 1200mm 1500mm 1500mm 2000mm 2000mm
Without casing 1600mm 2000mm 2000mm 2500mm 2500mm
Max. drilling depth 50m(5 section);                              40m(standard 4 section) 54m(5 section);                              42m(4 section) 60m(5 section); 48m(4 section) 65m(5 section); 52m(4 section) 70m(5 section); 56m(4 section) 88m(6 section);                         74m(Standard 5 section)
Pull-Down cylinder Max. pull-down piston push 114KN 160KN 160KN 160KN 180KN 190KN
Max. pull-down piston pull 148KN 180KN 180KN 180KN 215KN 220KN
Max. pull-down piston stroke 3.8m 5.0m 5.0m 5.0m 6m 6m
Main winch Max. pulling force 135KN 150KN(1st layer) 180KN(1st layer) 200KN(1st layer) 230KN(1st layer) 260KN(1st layer)
Max. line speed ≥70m/min 80m/min ≥65m/min ≥65m/min ≥65m/min ≥60m/min
Auxiliary winch Max. pulling force 60KN(1st layer) 75KN(1st layer) 80KN(1st layer) 80KN(1st layer) 100KN(1st layer) 100KN(1st layer)
Max. line speed ≥70m/min ≥70m/min ≥60m/min ≥60m/min ≥65m/min ≥65m/min
Mast rake Side/forwards ±3°/5° ±5°/5°/15° ±8°/5°/15° ±8°/5°/15° ±8°/5°/15° ±4°/5°/15°
Undercarrige Max. traveling speed 2.0km/h 2.0km/h 1.5km/h 1.5km/h 1.5km/h 1.5km/h
Max. grade ability 40% 40% 40% 40% 40% 40%
Min. Clearance 350mm 460mm 468mm 468mm 425mm 425mm
Track shoe width 700/800mm 600mm 800mm 800mm 800mm 800mm
Distance between tracks 2250~3300mm 2340~3340mm 3500~4400mm 3500~4400mm 3500~4800mm 3500~4800mm
Hydraulic system Working pressure 30Mpa 30Mpa 30Mpa 32Mpa 32Mpa 32Mpa
Overall drilling weight 40t 56t 68t 70t 80t 82t
Dimension Working condition 7310×4000/4100×17260mm 8105×3940×18230mm 10200×4400×20850mm 10200×4400×21700mm 10670×4800×22922mm 10670×4800×23146mm
Transportation condition 13200×2950/3050×3460mm 13645×2940×3380mm 15700×3500×3350mm 16120×3500×3378mm 17145×3500×3450mm 17380×3500×3494mm
