2013 Best-selling ! HF138Y Crawler Type Hydraulic Borehole Drillling Tools With Air Compressor

US$ 24,000 - 75,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Rotary Drilling Rig

Power Type:

Diesel

Zhengzhou Han Fa Imp & Exp Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Rotary Drilling Rig

Power Type Diesel

Place of Origin Henan, China

Brand Name HF

Model Number HF138Y

Usage Other, DTH

Dimension(L*W*H) 5200*2030*2300mm

Weight 5200*2030*2300mm

Certification ISO9001

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

HF138Y borehole drilling tools
1,use with air compressor
2, drill 90-130mm ,30-40m depth
3. crawler type

2013 Best-selling ! HF138Y Crawler type Hydraulic borehole drillling tools

with air compressor

1.Advantages---HF138Y Hydraulic movable drill

2. Main technicla parameters of HF138Y:

Main technical parameters of HF138Y
Wind pressure (Mpa)	0.7----1.6
Air consumption (m³/min)	10----15
Drilling diameter (mm)	90----130((max:203)
Drilling depth (m)	level 40m,down 80m
Once promotion distance (mm)	3000
Drill diameter (mm)	60
Skid compensation (mm)	900
Maximum lift force (N)	24900
Skid pitch (°)	up and down total 95
Swinging angle of skid (°)	Left 38, right 31
Boom Pitch (°)	up and down total 70
Boom swing angle (°)	Left 41, right 33
Grade ability (°)	30
Chassis ground clearance (mm)	260
Travelling speed (km/h)	2
Back to the transit speed (r/min)	0----80
Rotary torque (N.m)	2000
Host Power (Kw)	45
For rock (f)	6----20
Impact frequency (r/min)	950---1500
Total Weight (kg)	3800
Dimension (L * W * H)	520020302300
The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and other Rock blasting hole drilling
