Most Popular model HF-6 Full Hydraulic Core drilling rig
- 20 Set / Sets per Month
- Qingdao
-
3NB9/1.8-7.5 mining mud pump is used for providing cooling and flushing fluid during rock core or coal seam drilling
-
2NB3/1.5-2.2 mining mud pump is a vertical, double cylinder, single acting plunger pump
-
The 3NB-250/6-15 reciprocating mud pump provides washout fluid to the borehole during core drilling with the three-cylinder plunger
-
Coal mine tunnel drilling rig ZLJ350 head can be turned
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
Product Details
| Condition: | New | Type: | Core Drilling Rig | Place of Origin: | Henan, China |
| Brand Name: | Hanfa | Model Number: | HF-6 | Usage: | Ore |
Product Description
Specifications
HF-6 Full Hydraulic Core drilling rig1.Full hydraulic
2.Fabulous quality
3.Great Ability
4.Imported accessaries
HF-6 Full Hydraulic Core Drilling Rig
I. General Introduction
HF-6 Hydraulic Core Drilling Rig,an up-to-date new product,is a thoroughly new-typed drilling rig developed on the basis of the advanced techniques in the world. HF-6 is reasonable in design, excellent in performance, easy for operation and convenient for maintenance.
II. Main Performance Parameters of HF-6
The figures in these tables have been calculated, based on field experiences, and may be reasonably expected.
Actual drilling capacity will depend on in-hold tools and conditions, drilling techniques and equipment used.
Diesel Engine | Model | Cummins 6CTA (turbocharged and charge water cooled) |
Displacement | 8.3L (2.19 US Gallons) | |
Power | 178kW (240HP) | |
Rated RPM(Factory setting) | 2200rpm | |
Drilling Capacity | BQ | 2000 m(6560 feet) |
NQ | 1600 m(5248 feet) | |
HQ | 1300 m(4264 feet) | |
PQ | 1000 m(3280 feet) | |
Drill Head | Rotation Motor | Double Hydraulic Motor -variable and Reversible Maker: SAUER-DANFOSS |
RPM | Two Shifts/ Stepless Change 0-1100 RPM | |
Ratios | 1st 8.776:1 2nd 2.716:1 | |
Head Opener | sidewise sliding way with hydraulic drive | |
Hydraulic Chuck(PQ) | Hydraulically opened, Disc Spring Clamping, Normally C Closed Type Axial Holding Capacity of 222 400 N | |
Max. Torque | 6400 N·m(4717 lbf·ft) | |
Hold Diameter | 121 mm(4.76 inch) | |
Max. Lifting capacity of Spindle | 220 kN(49456 lbf) | |
Max. Feeding Power | 110 kN(24728 lbf) |
Primary Pump | Hydraulic pump: Axial Piston variable displacement Triplex pump for driving of rotator, winch mud pump & leveling jacks.With load sensing system. | Maker: DANFOSS 1st Pump:200LPM at 31.5MPa 2nd Pump:120LPM at 28MPa 3rd Pump:102 LPM at 16MPa |
Hydraulic Tank | Capacity | 420 L (111 US Gallons) |
Capacity of Main Hoist | Hoisting Speed (single wire) | 38-70m/min(bare drum) |
Hoisting force (single wire) | 120kN(26976 lbf) | |
Steel Wire Diameter | 22 mm(0.86 inch) | |
Steel Wire Length | 50 m(164 feet) | |
Capacityof Wireline Hoist | Hoisting Force (single wire) | 15 kN(3372 lbf) (bare drum) |
Steel Wire Diameter | 6 mm(0.24 inch) | |
Steel Wire Length | 2000 m(6560 feet) | |
Mast | Mast Height | 11 m(36 feet) |
Mast Adjusting Angle | 0—90 degrees | |
Drilling Angle | 45º off horizontal to 90ºvertical down | |
Feeding Stroke | 3800 mm(150 inch) | |
Slippage Stroke | 1500 mm(59 inch) | |
Feed Pull | 22000kg(48510 lb) | |
Feed Thrust | 11000kg(24255 lb) | |
Rod Pull | 3m or 6m(9.84feet or 19.68feet) | |
Mud Pump | Type | Reciprocating Pump Triplex Plunger |
Model | BW320 | |
Stroke | 110mm(4.3 inch) | |
Output volume | 320,230,165,118 L/min (84.5, 61, 44, 31 US Gallons/min) | |
Discharge pressure | 4.0, 5.0, 6.0, 8.0 Mpa (580, 725, 870, 1160 psi) |
Foot Clamp | Clamping Scope | 55.5-117.5 mm(2.19-4.63 inch) through hole dia.154mm(6.06 inch) |
Others | Weight | 14500 Kg(31973 lb) |
Transport Dimensions (L *W *H ) | 5900*2240*2500mm (232.3*88.1*98.4 inch) | |
Transport Way | Steel Crawler |
