HUANCHUANG Single Shaft Shredders have small to medium size reduction machines suitable for processing a wide range of materials to a uniform particle size. The products can often be sold as is, or be sent for further processing through additional equipment. Throughputs typically range between300kg/hr –5,000kg/hr+ depending on the model, material type and application as below:
• Plastics –Mouldings, Purgings/Lump, Profiles, Films etc.
• Timber/Wood – Pallets, Joiners Waste, Green Waste etc.
• Paper & Cardboard – Confidential Documents, Production Waste, Packaging Materials etc.
• Copper Cable – Household, Telecoms and Industrial Cables including S.W.A
• Aluminum – Used Beverage Cans (UBC’s), Swarf, Cables etc.
• Textiles – Carpet (Rolls & Tiles), Garments etc.
• Security Destruction – Counterfeit Items, Faulty Goods, Out of Date Stock etc.
• Foam – Production Waste etc.
A Selection of Videos showing the shredders processing the above application:
Advantages and Features
• Energy Efficient + Maximum Cutting Force & Productivity
• Shock Absorbing Gearbox reduces Stress on Drive Components
• Rotor Knives can be rotated and used on four edges before replacement.
• Long Life Counter Knives can be adjusted to maintain cutter clearance
• Quick Change Screens for accurate particle size control
• Segmented Shredding Chamber Floor with Brass Guides & PU Slides
• Twin Speed Hydraulics with integrated air cooler
• Stand Alone Electrical Control Panel with Siemens PLC Control System
• Tested, Approved and Certified to the applicable CE safety standards
For technical data or more information please contact Mr.Bob Li.
| Model | HC-SS-2250 | HC-SS-2260 |
| Dimension L/W/H(mm) | 2035*1300*1820 | 2035*1400*1820 |
| Shredding Chamber C/D(mm) | 740*505 | 740*605 |
| Height of discharge port E(mm) | 520 | 520 |
| Cylinder Stroke (mm) | 500 | 500 |
| Rotor Diameter (mm) | 220 | 220 |
| Main Shaft Speed(r/min) | 82 | 82 |
| Screen Mesh(mm) | 40 | 40 |
| Rotor knives(PCS) | 18 | 23 |
| Counter knives(PCS) | 4 | 4 |
| Main Motor Power(KW) | 15 | 18.5 |
| Hydraulic Motor Power(KW) | 1.5 | 1.5 |
| Gross Weight(KG) | 1500 | 1650 |
