HUALI Low Temperature Water Chiller

A.Features:

1. Low Temperature Water Chiller's modules units include single module type and combined (according to user's requirements) multiple modules type.

2. Low Temperature Water Chiller has advanced semi-hermetic twin-screw compressors (or piston compressor) and imported temperature controls of high quality to ensure the unit's performance.

3. Computer control, easy operation.

4. Water Chiller is auto capacity regulation, including multi-stage or stepless (25%~100% continuous) modes.

5. Imported latest semi-hermetic twin-screw compressor (or piston compressor) with features of precision and durability.

B.Cooling capacity:

--Refrigerant:R22
water outlet temp. 0 Deg C:71KW-2369KW

water outlet temp. -5 Deg C:67KW-2281KW

water outlet temp. -10 Deg C:55KW-1844KW

water outlet temp. -15Deg C:45KW-1523KW

water outlet temp. -35Deg C:17KW-625KW

--Refrigerant:R404A
water outlet temp. 0 Deg C:70KW-2233KW

water outlet temp. -5 Deg C:70KW-2254KW

water outlet temp. -10 Deg C:59KW-1886KW

water outlet temp. -15Deg C:49KW-1561KW

water outlet temp. -35Deg C:19KW-602KW

HUALI water cooled chiller is one of our leading products. This series is widely used in hotel, theatre,

office building and supermarket. Also are used in refrigerating fields, such as food industries, plastic factory,

pharmaceutical factories, and apparatus industries.

1)Plastics industry

2)Electronic industry

3)Electroplating industry

4)Mechanical industry

5)Building industry

6)Vacuum coating

7)Food industry

8)Chemical fiber industry

9)etc..

  1)Phase reversion protection,

 2)Phase lack protection,

 3)Overload current protection,

 4)Discharge air temp. protection,

 5)Low & High pressure protection,

 6)Low temp. protection,

 7)Water flow protection.

Shenzhen Jinhuali Technology Co.,Ltd. is a modern large enterprise, which integrates technology, industry and trade. It is a professional enterprise that provides central A/C, refrigeration plant, eletromechanical device, electric equipment and electronics, as engineering design and installation service. HUALI takes an area of over 100,000m2  with an asset of more than 100 millions and empolyee of more than 500 persons, and its has 5 branch companies in the rest of China.
