Iqege-1 Automatic specimen cutting machine
Brief introduction:
Iqege-1 Automatic specimen cutting machine is composed of machine frame, electric cabinet, cutting chamber, motor, cooling system and cutting grinding wheel etc. this machine can not only cut the round work piece with diameter less than 100mm, but also cut the rectangle work piece with height 100mm and depth 200mm. in order to prevent burning out the specimen during cutting period, the machine can cool the specimen by cooling system. It can also be set the cutting speed for the different cutting specimen so as to improve the specimen quality. This machine can be devided into manual cutting and automatic cutting. Big volume cutting chamber for user, it is necessary specimen cutting equipment for universities and colleges.
Technical parameters:
1,Power supply:three-phase (380v,50Hz)with safety to ground
2,Spindle speed:≥2000rmp/min
3,Grinding wheel 350mm×2.5mm×32mm
4,Max cutting capacity:≥φ95mm
5,Automatic cutting Max moving stroke:≥120mm;worktable Max moving stroke:≥250mm
6,Motor power:3KW
7,Stainless steel shell, anti-corrosion
8,Special design quick clamping jaw
9,Automatic feeding speed:0-15mm/min
10,Worktable dimension :330×280mm
11,Matched accessories according to customer’s requirement.
