MS Series scrape chain conveyor
Use and feature
The MS series scraper chain conveyor is a kind of chain conveyor fo barley, malt and other grains. As a conveyor equipment of powders or other loose small granular, all the moving parts are installed in the machine body so as to prevent the dust flying, it features: advanced motion index, simple and reasonable structure, nice sealing, fast assembly, safe operation, conveying distance can be optional
This machine can be divided into fixed model and combined model, it also can be adjusted to meet the different conveying distance through changing section quantity.
Item | MS25 | MS32 | MS40 | MS50 | |
Material volume t/m3 | 0.4-0.8 | 0.4-0.8 | 0.4-0.8 | 0.4-0.8 | |
Conveying capacity m3/h | 25-60 | 55-100 | 100-260 | 210-420 | |
Scraper chain speed m/s | 0.16-0.4 | 0.2-0.4 | 0.25-0.63 | 0.32-0.63 | |
Max conveying length m | <80 | <80 | <80 | <80 | |
Safe dip angle | 0-15 | 0-15 | 0-15 | 0-15 | |
Scraper chain | Space between scraper mm | 200 | 200 | 200 | 400 |
Chain pitch mm | 100 | 100 | 100 | 200 | |
Cylinder diameter mm | 28 | 28 | 28 | 45 | |
Chain type | TG100 | TG100 | TG200 | TG200 | |
Weight / meter kg | 7.91 | 7.91 | 7.91 | 16.8 | |
Please feel free to contact us if you are interested in our products, we would like to offer top quality and best service for you!
