Advantages of our CCD Sensor plastic color sorting machine/ color sorter machine:
1.Carryover 20:1
2.High Sensitivity
3.High Accuracy 99.99%
4.High Stability
5.High output
Technicial Features:
1. Leading LED light source technology,featured with high efficiency, long service life, strong anti-interference ability
2. Adapt 2048-pixel high-speed high resolution CCD sensor and high-precision camera lens;can accurately identify as small as 0.02 mm2 heterochromatic areas and easily identify light yellow, belly-white and small disease spots.
3. Adopt high-quality, high-frequency, Long service life, low air consumption, can guarantee maximum output, low carryover ratio and low failure rate.
4. The unique direct air ejector significantly reduces air resistance and air consumption, responds more quickly, and creates better aiming accuracy, can reduces carryover ratio as well.
5. The ARM+FPGA double core system can enable top-level computing and processing ability.
6. Specific optimum corresponding working mode designed for different kinds of rice, one machine can sort different kinds of rice.
7. New power supply system, low energy consumption, can reduce cost, and can help to avoid adverse effect caused by sudden voltage change, therefore to realize long-term stable operation.
8. Auto-self-detection function, can automatically detect faults of ejectors, pressure, control board and background board etc; therefore is user friendly and time, energy efficient.
9. Specially designed discharge system, can greatly reduce the product carryover.
10. Sealed control box can protect key components from dust, so the machine will few mechanical stoppage, and therefore to extend service life.
11. The powerful smart software operation system is easy to learn and to use. The colorful touch panel is user friendly and pleasant.
Technical parameters:
(Model NO.) | MS-G640 | MS-G1280 | |
(T/H)(Output) | ≤2.5 | ≤5 | |
(%)(Accuracy) | ≥99.3 | ≥99.3 | |
(Optimal Carryover) | ≥15:1 | ≥15:1 | |
(Voltage)(V) | AC220V 50HZ | AC220V 50HZ | |
(KW)(Power) | 2.7 | 3.5 | |
(Mpa)(Air Pressure) | 0.6~0.8 | 0.6~0.8 | |
(KG) (Weight) | 900 | 1200 | |
(L×W×H:MM) (Dimension) | 3310×900×2345 | 3310×1580×2645 | |
Note :
1. The above data is worked out base on plasticwith 3% impurity, it may vary according to different materials and different impurities percentage etc.
2. Update to the machine is allowed without notification. Please refer to the actual machine for more details.
Packaging details:packed according to customers’ requirement.
Delivery details:10-20 working days afer reeeive advance payment.
1.Free installation and commissioning
2.Free maintance for one year
3.Set office overseas and online operation instruction & solution within 24 h
4.Long life free upgrading software.
Hefei MINGDE Photoelectric Technology CO,. Ltd is a professional smart-color-sorter equipment research, development and production enterprise, which is located in China, Shuangfeng Economic Development Zone of Hefei city; owns a 40 acres industrial park including 2000square meters R&D center and standard factory; has the capacity to produce more than thousand machines and to generate more than 100 million output value per year.
The R&D team of MINGDE consisted of innovative experts and talent in photoelectric technology field, most of whom are graduates from Tsinghua University, University of Science and Technology of China etc. The goal of MINGDE is to achieve maximum customer satisfaction by developing smart, practical, user friendly and high quality products. So far, MINGDE has launched a series of smart color sort machine, whose intellectual property rights are owned by MINGDE completely. This series of product can accurately sort food material such as rice, cereal, tea etc. and industrial material including plastic, mineral and so on, which are successfully exported to America, Africa, Southeast Asia and other overseas markets. All series of the products are well respected within photoelectric color sorting field and praised by customers.
In MINGDE, our enterprise philosophy is that “Integrity is the basis for successes”. We devote to the creation of leading technology and innovation. We are willing to work with friends from all areas and to make brilliant contributions in photoelectric color sorting field.
What is our color sorters for ?
--For sorting your rice, grains, etc. material in good quality and rate
Do you have the warranty ?
--YES. We provide life-long time maintaining service.
What's the lead time ?
--About 10-20 working days according to your needs.
Do you acccept Custom-made order ?
--YES. WE DO ! We are manufacturer.
What is our color sorters for ?
--For sorting your rice, grains, etc. material in good quality and rate
Do you have the warranty ?
--YES. We provide life-long time maintaining service. 1 year
What's the lead time ?
--About 10-20 working days according to your needs.
Do you acccept Custom-made order ?
--YES. WE DO ! We are manufacturer.
Engineers overseas service abailable ?
YES !
========================================
