Help CenterSupplying Aluminum Products Finishing Equipment Article Points Rotary Shear
Related Products
-
Supplying Casting Machine Side Shearing/ Cutting Rotary ShearNegotiableMOQ: 1 Set -
Supplying Aluminum Foil Finishing Equipment Side Shearing/Cutting Rotary ShearNegotiableMOQ: 1 Set
-
Supplying Aluminum Hot Rolling Mill Side Shearing/ Cutting Rotary ShearNegotiableMOQ: 1 Set
-
Supplying Aluminum Foil Finishing Equipment Article Points Rotary ShearNegotiableMOQ: 1 Set
-
Supplying Aluminum Sheet/Plate Casting Machine Side Shearing/ Cutting Rotary ShearNegotiableMOQ: 1 Set
Specifications
Aluminum Products Finishing Equipment Article Points Rotary Shear is of high quality, high performance, high efficiency
1.Parameters of Rotary Shear
materials thickness |
0.08-5.0mm |
Maximum speed of circle shear |
500m/min |
product width |
3-5 mm |
Radial run-out of blade shaft |
below 0.01mm |
Axial run-out of blade shaft |
below 0.005mm |
Face run-out |
below 0.003mm |
Parallelism of blades shafts |
below 0.01mm |
Overlap |
below 0.02mm |
2.Rotary Shear Blueprint
3.Technical Parameters
Shearing Speed |
30--180m/min |
Chuck Diameter |
350--400 |
Chuck Opening Degree |
700--1350mm |
Blade Thickness |
35--40mm |
Blade Material |
6CrW2si |
Blade Shaft Material |
42CrMo |
Shearing Variables |
Min 5mm Max 35mm(unilateral) Max 35mm(unilateral) |
Shearing Steel Strip Thickness |
1.5--5mm |
Blade Overlap Ajustment Precision |
±0.03mm
|
Blade Clearance Adjustment Precision |
±0.005mm |
4.Patents our Rotary Shears have got:
Change blades swiftness patent
Wide strip edge cutting patent
Should any of our concrete products be of your interest, please feel free to contact me, I am ready to provide you any information that you concern. I am looking forward to establishing long term business relationship with you!
