Specifications
ALuminum Casting Machine Side Shearing/Cutting Rotary Shear has gotten both Fast Tool Change Device Patten.1. Seiko Shear Accuracy Indexes
sheet thickness | below 0.5 | 0.5~3 | above 3 |
Shear shaft circle runout | below 0.005 | below 0.015 | below 0.03 |
Shear head positioning face runout | below 0.002 | below 0.008 | below 0.02 |
Side clearance adjustment precision | ±0.005 | ±0.01 | ±0.03 |
Overlap adjustment precision | ±0.03 | ±0.05 | ±0.05 |
opening adjustment precision | 0~0.5 | 0~1 | |
2. Technical Parameters
Shearing Speed | 30--180m/min |
Chuck Diameter | 350--400 |
Chuck Opening Degree | 700--1350mm |
Blade Thickness | 35--40mm |
Blade Material | 6CrW2si |
Blade Shaft Material | 42CrMo |
Shearing Variables | Min 5mm Max 35mm(unilateral) Max 35mm(unilateral) |
Shearing Steel Strip Thickness | 1.5--5mm |
Blade Overlap Ajustment Precision | ±0.03mm
|
Blade Clearance Adjustment Precision | ±0.005mm |
3.The Brief Introduction of Rotary Shear with Seiko Design and Manufacture
It can be used for metal strip longitudinal trimming or slitting. One is dynamic shear, another is
passive tensile shear. There are various models, such as, Twin Towers Rotary Shear, Cantilevered Rotary Shear,
Through Axle Rotary Shear and so on. At present, more than 80 sets of our Rotary Shear service in steel and non-ferrous metal industry.
Our customers include Panzhihua Iron and Steel , Wuhan Iron and Steel , Hengshui Board Industry,
Kunming Iron and Steel etc.
4.The scope of Seiko Rotary Shear
Metal strip material: plain carbon steel, stainless steel, silicon steel, titanium alloy, Nichrome alloy, aluminum alloy, copper alloy.
Should any of our Rotary Shear be of your interest, please feel free to contact me ,I am ready to provide you any inforamtion that you concern, I am looking forward to establishing long term business relationship with you!
