Help CenterHigh Quality and High Performance Cold Rolling Mill Side Shearing and Cutting Rotary Shear
Related Products
-
PE Protective Film for Wrap Pallets or FoodsNegotiableMOQ: 10 Rolls -
PE Protective Film for PhoneNegotiableMOQ: 10 Rolls
-
Hot Sales PE Protective Film for Plastic Sheet (PVC, ABS, PS, PC, PMMA))NegotiableMOQ: 10 Rolls
-
Supply PE Protective Film for Automobile (interior Carpet, Floor, Sets, Lamp, Door Panel, Hood)NegotiableMOQ: 10 Rolls
-
Rotary Shear Balde MachineryNegotiableMOQ: 1 Set
Specifications
Cold Rolling Mill Side Shearing and Cutting Rotary Shear is of high quality and high performance and competitive price.1. Technical Parameters
Shearing Speed | 30--180m/min |
Chuck Diameter | 350--400 |
Chuck Opening Degree | 700--1350mm |
Blade Thickness | 35--40mm |
Blade Material | 6CrW2si |
Blade Shaft Material | 42CrMo |
Shearing Variables | Min 5mm Max 35mm(unilateral) Max 35mm(unilateral) |
Shearing Steel Strip Thickness | 1.5--5mm |
Blade Overlap Ajustment Precision | ±0.03mm
|
Blade Clearance Adjustment Precision | ±0.005mm |
2.Rotary Shear Blueprint
3. Rotary Shear Unit Information
Rotary Shear Unit
Specifications and Models | Thinkness | Width | Coil Material Weight | Finished Products Width | Article Number | Shearing Speed |
2X1600 | 0.3-2mm | 900-1550mm | 30T | ≥40mm | ≤20 | 60m/min |
4X1600 | 0.5-4mm | 900-1550mm | 30T | ≥60mm | ≤13 | 50m/min |
6X1600 | 1-6mm | 900-1550mm | 30T | ≥60mm | ≤10 | 40m/min |
8X1800 | 2-8mm | 900-1800mm | 30T | ≥70mm | ≤6 | 30m/min |
10X2000 | 3-10mm | 900-2000mm | 30T | ≥80mm | ≤5 | 25m/min |
12X2000 | 3-12mm | 900-2000mm | 30T | ≥100mm | ≤5 | 20m/min |
4.The Function of Casting Machine Article Points Rotary Shear
This machine is used to make various the lapped tape and sheet material into artical number, then recoiled them.
5 About our company
We are Zhengzhou Hengzhong Heavy Machinery Manufacturing Co., Ltd. It is an aluminum equipment company which integrates design, manufacture an installation. Our company has strong technical force, advanced production capacity and excellent after-sale service. Our products have been recongnized an appreciated by both the old and the new customaers. Now, our products have been sold very well all over China and have been exported to the Middle East. It has made us one of the best leaders in the aluminum processing industry.
6.Our concrete products
Our concrete products include such as Aluminum Casting Machine, Aluminum Cold Rolling Mill, Aluminum Foil Rolling Mill, Aluminum Cleaning Machine, Tension Leveling Line, Cut-to-length-line, Cast Roller, Cast Roller Shell, Rotary Shear, Coiler, Recoiler.
Should any of our Rotary Shear be of your interest, please feel free to contact me, I am ready to provide you any information that you concern. I am looking forward to establishing long term business relationship with you!
