Help CenterGood Price and Service Aluminum Foil Rolling Mill With Various Types of Rolling Machines Making Machines
Related Products
-
World-class Quality Aluminum Foil Rolling Mill in China is Best SaleNegotiableMOQ: 1 Set -
BRAND: HZZG Aluminum Foil Rolling Mill With Various Types of Rolling Machines Making MachinesNegotiableMOQ: 1 Set
-
SIEMENS OMRON Aluminum Foil Rolling MillUS$ 500,000 - 700,000MOQ: 1 Set
-
Supply ISO9001 Approved Aluminum Foil Rolling MillUS$ 250,000 - 500,000MOQ: 1 Set
-
Aluminum Foil Rolling Mill Machine Production LineUS$ 540,000 - 1,400,000MOQ: 1 Set
1 Technical parameter of aluminum foil rolling mill :
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 0.6 max mm |
Dia. of work roll | 200~320 mm |
Width of work roller | 800~2300 |
Dia. of back up roll | Φ550~850 mm |
(mm) Width of back-up roller | 750~2250 mm |
Weight of coil | 30000 max kg |
Foil rough-rolling thickness | 0.05~0.2 mm |
Thickness of Foil medium-rolling | 0.1 mm |
Thickness of foil rolling (double sheet) | mm |
Rolling speed | 2000 max m/min |
Exit of Al foil width | 700~2080 mm |
Rolling form Non-reversing | Non-reversing |
ABB Electric control system | SIEMENS OMRON |
2 Advantage of aluminum foil rolling mill
A. Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control system (AGC).
B. Piecewise controlled cooling system .
C. Advanced pre-coated plate filtration system.
D. Automatic and manual controlled CO2 fire extinguishing system.
E. Full digital control and network communication, aim to provide control accuracy and reliability.
F. Advanced engineering workstations.
G. The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.
H. 12 inch color LCD operator terminals, easy to operate and display.
3 Pictures show:
4 Application :
Mainly used in package for food,drinking,cigarette,Pharmaceutical,photograph,daily necessities,power capacitor,construction,auto,boat,celling,lable,etc
Any request, please contact us without hesitation.We cordially welcome friends all over the world. We are looking forward to having the chance of cooperating with you in the near furture.
