Top Sell Two Weekly Aluminum Foil Rolling Mill

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Cold Rolling Mill
Place of Origin	Henan, China	Brand Name	HZZG
Model Number	Customized	Voltage	380v
Power(W)	150KW	Dimension(LWH)	According to customers' requirement
Weight	15T--50T	Certification	ISO9001: 2008 certificate
Warranty	12 months	After-sales Service Provided	Engineers available to service machinery overseas

Technical parameter of aluminum foil rolling mill :

Aluminum alloy	1000,3000,8000 series
Entry thickness	0.6 max mm
Dia. of work roll	200~320 mm
Width of work roller	800~2300
Dia. of back up roll	Φ550~850 mm
(mm) Width of back-up roller	750~2250 mm
Weight of coil	30000 max kg
Foil rough-rolling thickness	0.05~0.2 mm
Thickness of Foil medium-rolling	0.1 mm
Thickness of foil rolling (double sheet)	mm
Rolling speed	2000 max m/min
Exit of Al foil width	700~2080 mm
Rolling form Non-reversing	Non-reversing
ABB Electric control system	SIEMENS OMRON

1. Advantage of aluminum foil rolling mill

A. Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control system (AGC).

B. Piecewise controlled cooling system .

C. Advanced pre-coated plate filtration system.

D. Automatic and manual controlled CO2 fire extinguishing system.

E. Full digital control and network communication, aim to provide control accuracy and reliability.

F. Advanced engineering workstations.

G. The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.

H. 12 inch color LCD operator terminals, easy to operate and display.

2.Pictures show:

We cordially welcome friends all over the world. We are looking forward to having the chance of cooperating with you in the near furture.
