Help CenterNon-reversing Aluminum Foil Packaging Foil Roll Mill Eqipment
Related Products
-
High Quality Competitive Price Aluminum Alloy Foil Roll Mill Equipment ManufacturerNegotiableMOQ: 1 Set -
Hot Sale High Quality Competitive Price Aluminum Plate Foil Roll Mill Eqipment in SupplyNegotiableMOQ: 1 Set
-
Hot Sale High Quality Competitive Price Aluminum Foil Rolling Mill Equipment ManufacturerNegotiableMOQ: 1 Set
-
Aluminum Foil Mill Rolls for Aluminum FoilsNegotiableMOQ: 1 Set
-
Aluminum Alloy Sheet Foil Cold Rolling Mill on Hot SaleNegotiableMOQ: 1 Set
Specifications
Our Aluminum Foil Rolling Mill is of high quality, high performance, high efficiency and excellent service.1 Technical Parameters of Aluminum Foil Roll Mill Equipment
Aluminum alloy |
1000,3000,8000 series |
Entry thickness |
0.6 max mm |
Dia. of working roll |
200~320 mm |
Width of work roller |
800~2300mm |
Dia. of back up roll |
Φ550~850 mm |
Width of back-up roller |
750~2250 mm |
Weight of coil |
30000 max kg |
Foil rough-rolling thickness |
0.05~0.2 mm |
Thickness of foil medium-rolling |
0.1 mm |
Thickness of foil rolling (double sheet) |
mm |
Rolling speed |
2000 max m/min |
Exit of Al foil width |
700~2080 mm |
Rolling form |
Non-reversing |
Electric control system |
SIEMENS OMRON |
2.About our company
We are Zhengzhou Hengzhong Heavy Machinery Manufacturing Co., Ltd. It is an aluminum equipment company which integrates design,manufacture and installation. Our company has absolute technical force, advanced production capacity and excellent after-sale service. Our products have been recognized and appreciated by both the old and the new customers. Now, our products have been sold very well all over China and have been exported to the Middle East. It makes us one of the best sellers in the aluminum processing equipment industry.
3.About our concrete products
Our concrete products include such as Aluminum Casting Machine, Aluminum Cold Rolling Mill, Aluminum Foil Rolling Mill, Aluminum Cleaning Line, Tension Leveling Line, Cut-to-length-line, Cast Roll, Cast Roller,Aluminum Sheet, Aluminum Circle, and other aluminum related.
Should any of our products be of your interest, please feel free to contact me, I am ready to provide you any information that you concern. I am looking forward to establishing business relationship with you!
