Specifications
Our Aluminum Foil Roll is of high quality, high performance and high efficiency..
1.Technical Parameters
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 0.6 max mm |
Dia. of working roll | 200~320 mm |
Width of work roller | 800~2300mm |
Dia. of back up roll | Φ550~850 mm |
Width of back-up roller | 750~2250 mm |
Weight of coil | 30000 max kg |
Foil rough-rolling thickness | 0.05~0.2 mm |
Thickness of foil medium-rolling | 0.1 mm |
Thickness of foil rolling (double sheet) | mm |
Rolling speed | 2000 max m/min |
Exit of Al foil width | 700~2080 mm |
Rolling form | Non-reversing |
Electric control system | SIEMENS OMRON |
2.Advantages
1. Aluminum foil rolling mill has an advanced hydraulic pressure on
the thickness of the automatic control system (AGC)
2. Piecewise controlled cooling system .
3. Advanced pre-coated plate filtration system.
4. Automatic and manual controlled CO2 fire extinguishing system.
3.Our concrete products
Our concrete products include such as Aluminum Casting Machine, Aluminum Foil Rolling Mill, Aluminum Cold Rolling Mill, Aluminum Cleaning Line, Tension Leveling Line, Cut-to-length-line, Cast Roll, Cast Roller, Aluminum Sheet, Aluminum Circle and other aluminum related.
Should any of products be of your interest, please fell free to contact me, I am ready to provide you any information that you concern. I am lookibf forward to establishig long term business relationship with you!
