Help CenterAluminum Plates /Sheets Cold Rolling Mill
Related Products
-
SIEMENS OMRON Aluminum Cold Rolling MillNegotiableMOQ: 1 Set -
Good Service Aluminum Strip Cold Rolling Mill for SalesUS$ 6,000,000 - 6,000,000MOQ: 1 Set
-
1000 Series Aluminum Strip Cold Rolling Mill for SalesUS$ 6,000,000 - 6,000,000MOQ: 1 Set
-
1000 3000 Aluminum Alloy Aluminum Strip Cold Rolling Mill for SalesUS$ 6,000,000 - 6,000,000MOQ: 1 Set
-
High Speed 1000 3000 8000 Aluminum Alloy Aluminum Strip Cold Rolling Mill for SalesUS$ 6,000,000 - 6,000,000MOQ: 1 Set
Specifications
The Cold Rolling Mill is of high precision and high out-put.It is highly automatic and easy to operate and maintance.1. Technical Parameters
Project |
Technical Parameters Name |
Unit |
Technical Parameters |
|
Material specification |
Alloy:1xxx, 3xxx, 5xxx,8xxx series |
|||
Coil width |
mm |
700—2000 |
||
Coil thickness |
mm |
8 (Max) |
||
Outer diameter |
mm |
Ø1000—Ø1900 |
||
Inner diameter |
mm |
Ø510,Ø610 |
||
Max coil weight |
Kg |
13000 |
||
Finished products |
Coil width |
mm |
700—2000 |
|
Coil thickness |
mm |
0.05(Min) |
||
Guarantee of equipment configure |
Rolling force |
mm |
7000—20000 |
|
Surface speed of work roll |
M/min |
600—1200 |
||
Work roll |
mm |
Ø510 Ø610 |
||
Back-up roll |
mm |
Ø510 Ø610 |
||
Reduction rate |
|
30%--60% |
||
2.Installing Level
(1) with advanced hydraulic and automatic control system(AGC )
(2) Advanced pre-coating filter system
(3) Digital control and network communication to control the precision and reliability
Should any of our products be of your interest, please feel free to contact me, I am ready to provide you any information that you concern. Lokking forward to establishing long term business relationship with you!
