Specifications
(1)used in aluminum industry(2)used for rollinfg thiner aluminum sheet
(3) good quality and stable performance
Specifications:
(1) For aluminum strip cold rolling line
(2)Hydraulic drive
(3)Expanding Mandrel
(4)ISO9001:2008
Technical Data
Aluminum Cold Rolling Mill is used for rolling upto 10mm casting coils into 0.1-4 mmrough thickness and 0.5-0.6mm finishg rolling coils
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 10Max mm |
Entry width | 1000~2300mm |
Dia. of work roll | Φ280~560 mm |
Width of work roller | 850~2500 mm |
Dia. of back-up roll | Φ600~1500 mm |
Width of back-up roller | 800~2450 mm |
Width of exit | 950~2250 mm |
O.D. of coil | Φ2500 max mm |
Weight of coil | 20000 max kg |
Rolling speed | 1000max mm/min |
Rough rolling exit thickness | 0.1~4.0 mm |
Finishing rolling exit thickness | 0.5~0.06 mm |
Rolling mode | Non-reversing |
ABB Electric control system | SIEMENS OMRON |
Model type(cold rolling machine) | Φ280/φ780×1450 |
Φ380/φ960×1650 | |
Φ420/φ1100×1850 | |
Φ460/φ1300×2300 |
Should any of our products be of your interest, please feel free to contact me, Looking forward to establishing long ternm business relationship with you!
