Specifications
4 hi cold rolling mill1. Simple structure & easy to operate
2. Low cost and high efficiency.
3. Full-automatic control
supply 4 hi aluminum cold rolling mill machine
4 hi cold rolling mill / 4 hi aluminum cold rolling mill / aluminum cold rolling mill
Technical Parameters of 4 hi aluminum cold rolling mill
Aluminum alloy |
1000,3000,8000 series |
Entry thickness |
10Max mm |
Entry width |
1000~2300mm |
Dia. of work roll |
Φ280~560 mm |
Width of work roller |
850~2500 mm |
Dia. of back-up roll |
Φ600~1500 mm |
Width of back-up roller |
800~2450 mm |
Width of exit |
950~2250 mm |
O.D. of coil |
MaxΦ2500 mm |
Weight of coil |
Max 20000 kg |
Rolling speed |
Max 1000 mm/min |
Rough rolling exit thickness |
0.1~4.0 mm |
Finishing rolling exit thickness |
0.5~0.6 mm |
Rolling mode Non-reversing |
Non-reversing |
ABB Electric control system |
SIEMENS OMRON |
|
Model type
|
Φ280/φ780×1450 |
Φ380/φ960×1650 | |
Φ420/φ1100×1850 | |
Φ460/φ1300×2300 |
Advantages of 4 hi aluminum cold rolling mill
The cold rolling mill manufactured by our company adopts up uncoiler , up recoiler and elevated overall structure , during rolling, the strip sides change but the surfaces do not change , which effectively ensure the internal structure and surface quality of the strip , the cold rolling mill has reasonable arrangement with wide operation visual field ,high automation , convenient daily operation and maintenance.
- Design of installations, Manufacturing of equipment
- Installations, commissioning and training
- One year guarantee except consumptive part
- 24 hours technical support by e-mail
- Calling or door-to-door service
For more information, please feel free to contact me. I am ready to provide you any information about our products that you concern.
TEL: +86 0371 64100199
FAX: +86 0371 64100299
MB: +86 13703951067
Skype: Lezard Zhang
4 hi cold rolling mill / 4 hi aluminum cold rolling mill / aluminum cold rolling mill
