Specifications
Cold rolling machine1,Used in aluminum processing industry
2,Supply auxiliary equipment&accessories
3,High quality
Cold rolling machine detailed description
Cold rolling mill can roll the aluminium cast coils or hot rolled coils of thickness 6~8mm down to the finished products of thickness 2~0.05mm after several passes. Cold rolling mill is equipped with advanced hydraulic automatic gauge control (AGC) system and perfect advanced automatic flatness control (AFC) system which can provide many kinds of control methods such as roll tilting, positive and negative work roll bending and roll cooling in segments. According to the customer need, the mill can be equipped with state-of-art AFC system to roll out the optimized flat products in terms of thickness and flatness precision. All the DC motors can be supplied power by the advanced full digital thyristor due to the high automation of the mill. PLC (programmable controller) is used to carry out the advanced electric control such as digital logical calculation, data set-up, automatical control etc. At the same time, the mill is also equipped with various perfect accessory systems such as advanced plate filter, safe and liableCO2 automatical fire extinguishing system, lubricating system, dry air blow off device, fume exhaust device, and accurate strip deviation detecting system etc. to provide liable guarantee for producing good quality products.
1,Technical Parameter:(aluminum cold rolling machine)
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 10Max mm |
Entry width | 1000~2300mm |
Dia. of work roll | Φ280~560 mm |
Width of work roller | 850~2500 mm |
Dia. of back-up roll | Φ600~1500 mm |
Width of back-up roller | 800~2450 mm |
Width of exit | 950~2250 mm |
O.D. of coil | Φ2500 max mm |
Weight of coil | 20000 max kg |
Rolling speed | 1000max mm/min |
Rough rolling exit thickness | 0.1~4.0 mm |
Finishing rolling exit thickness | 0.5~0.06 mm |
Rolling mode | Non-reversing |
ABB Electric control system | SIEMENS OMRON |
Model type(cold rolling machine) | Φ280/φ780×1450 |
Φ380/φ960×1650 | |
Φ420/φ1100×1850 | |
Φ460/φ1300×2300 |
