The low consumption coal ball mill
Features and Benefits of coal ball mill
This machine changes the intrinsic grinding machine structure. Its body and ground plank are an integral whole, so when fixing, it can be lowered on a plane surface once only. Using double tiered roller axletree with centripetal spherical surface as the support of the host axletree can reduce energy cost by 30%.The intrinsic grille pattern forcing evacuation is instead by overfall pattern controlling one. It can improve the milling of the granule and the capacity be increased by 15-20%.
Main technical parameters of coal ball mill:
|
Model
|
Speed of bucket (r/min) |
Ball load (t) |
Feeding size (mm) |
Discharging size(mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (t) |
MQG900×2100 |
41 |
1.53 |
≤15 |
0.074-0.4 |
0.5-1.3 |
15 |
3.9 |
MQG1200×2800 |
36 |
4.22 |
≤20 |
0.074-0.4 |
1.5-3.7 |
37 |
9.52 |
MQG1500×3500 |
32 |
8.55 |
≤25 |
0.074-0.4 |
3.3-8.2 |
75 |
15.63 |
MQG1500×5700 |
31 |
10 |
≤25 |
0.074-0.4 |
3.8-12 |
95 |
25 |
MQG1830×3600 |
26.5 |
12 |
≤25 |
0.074-0.4 |
4.0-20 |
130 |
32 |
MQG2100×3600 |
24.1 |
19.6 |
≤25 |
0.074-0.4 |
7.6-42 |
180 |
43.5 |
MQG2400×3600 |
22.4 |
23 |
≤25 |
0.074-0.4 |
11-52 |
240 |
54.3 |
MQG2700×3600 |
21 |
27 |
≤25 |
0.074-0.4 |
15-70 |
280 |
78.5 |
Notice: Any change of the technical data shall not be advised additionally.
Detailed Description of super fine ball mill
The ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc,.And the ball mill can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.
12. Working Principle.
The barrel of grinder is driven by the motor through transmission and reduction gears to rotate at a proper speed. The grinding media in the rotating barrel is lifted to a certain height and then acts by tossing and falling, by which the material is impacted and grinded.
Ball mill accessories
About Us Zhengzhou Xinguang Mining Machinery Manufacturing Co., Ltd was founded in the 1980s, now has become a group company which own many branches in China and abroad. As a professional mining machinery manufacturer, we provides complete sets of mine selection machines, sand making equipment, cement making equipment, and compound fertilizer equipment, with a production capacity ranging from five tons to five thousand tons per day.
