High Quality ZL-15F Garden Mini Dumper Euro III
US$ 6,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
KAIWEI
Model Number:
ZL15F
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sell Mini Small Loader ZL-16 Pallet Fork for Wheel LoaderUS$ 8,000 - 12,000MOQ: 1 Set -
Hot Sell Mini Loader Machine ZL-16 Heavy Equipment ,farm MachineUS$ 8,000 - 9,900MOQ: 1 Set
-
CE Mini Wheel Loader ZL16f With Xinchai Engines(Euro III)US$ 6,000 - 8,000MOQ: 1 Set
-
China Made Wheel Loader ZL16f Mini Shovel Loader for SaleNegotiableMOQ: 1 Set
-
Hydrostatic Steering 1.5T Small Loader ZL16 With CEUS$ 3,000 - 9,000MOQ: 1 Set
Condition
New
Brand Name
KAIWEI
Model Number
ZL15F
Place of Origin
Shandong, China
Type
Front Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
4760X1680X2550
Rated Load
1500KG
Certification
CE, CE certification
Warranty
one year
Specifications
1.High quality garden mini dumper ZL-15F Euro III2.Streamlined design
3.Elegant appearance
4.Reliable quality
5.CE mark
Features:
- Adopting hydraulic-mechanical power shift transmission boix;
- Adopting central articulated frame and load-sensing hydraulic steering gear that can make the track of rear wheels of the front loader coincide with the track of its front wheels when turning to make the turning radius short, which enables it to work on a narrow site and makes it have easy and flexible operation, safe and reliable performance, compact structure and easy maintenance;
- Adopting four-wheel drive, low-pressure 16/70-20 bigger tire and pendular rear axle that can make the front loader have good off-road performance, trafficability and more traction;
- Fully enclosed cab with adjustable and suspension seat can provide comfortable driving and wide view;
- Using 12-16.5 ultra-wide tyres to increase the stability of the whole machine and the service life of tyre;
- Brake system adopts vacuum booster, air over hydraulic caliper disc brake on 4 wheels;
- This small wheel loader adopts ZL240 itegrated torque converter, and the whole machine is fully hydraulic transmission;
- This compact wheel loader can be optionally equipped with pilot control system to make it easy to operate and increase the exceptional performance of the whole machine;
- Power system adopts changchai 4L68, 4L50 direct injection, environmentally friendly, 4-cylinder engine to make this front loader have strong power and high acceleration, which greatly increase its high working efficiency;
- This compact wheel loader can be equipped with optional quick hitch (quickluck hydraulic coupler).
1.Using direct injection diesel engine as power, with easy start up and low oil consumption
2. Using special Isuzu drive axle, with strong ability to overcome obstacle
3. Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4. This machine uses mechanical gear box and hydraulic steering operation, with simple structure, convenient operation, good performance and reliable quality
5. Widely applying to the construcction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc.
1.High quality wheel loaders ZL-15F Euro III
2.Streamlined design
3.Elegant appearance
4.Reliable quality
5.Excellent price
Bitmap Bitmap
| |||||
| Specification | overall weight(kg) | 3600 | |||
| L×W×H(mm) | 4760X1680X2550 | ||||
| Rated bucket capacity(m3) | 0.7 | ||||
| Rated load(kg) | 1500 | ||||
| dump height (mm) | 2750 | ||||
| Bucket indicator | YES | ||||
| Max. breakout force(KN) | 43 | ||||
| Engine | Brand and modle | Changchai4L68/xinchai498 /490 EuroIII | |||
| Type | Four strokes, Water cooling, Inline, injecting combustion chamber |
||||
| Rated power(kw) | 37 | ||||
| Rated speed(r/min) | 2200 | ||||
| Transmission system | Model of torque converter | YJ240 | |||
| Type | single-phase single-stage radial-inward turbine triplex | ||||
| Gearbox type | Fixed-spindle power shift | ||||
| Gear shift | 2 gears ahead,2 gear astern | ||||
| Hydraulic system | Distribution of work valve | ZL20B | |||
| Working pump | CBGj1045,CBGq1018 | ||||
| Steering system | Type | Articulated hydraulic steering | |||
| Max. turning angle | 27±1° | ||||
| Min turning radius(mm) | 3000 | ||||
| Brake system | Brake type | Oil brake(Vacuum booster) | |||
| Tire | Standard tire | 14/90-16,12-16.5 |
|||
| Optional wide tyres | 14-17.5 | ||||
