Home > Products > water well drilling rig > 180m Hydraulic Geothermal Drilling Rig(sz180)
180m Hydraulic Geothermal Drilling Rig(sz180)
- Qingdao Port
- T/T Money Gram
You May Like
Product Details
| Condition | New | Type | Other | |
| Place of Origin | Shandong, China | Brand Name | longye | |
| Model Number | SZ-180 | Usage | Water Well |
Product Description
Specifications
SZ-180 hydraulic water well drilling rig use for drilling geothermal heating stoveSZ180 hydraulic water well drilling rig
have the character of light,high efficiency,multi-function.According to different conditions,it uses air,foam or slurry to rotate and drill.
Application:it is widely used in industrial and agriculture water project,drill water well,inspect well and other exploration borehole.which especially used for drilling geothermal heating stove.
Technical parameter;
Bore diameter | 127-254mm |
Bore depth | 213m |
Work pressure | 1.05-2.46Mpa |
Air consumption | 16-30m3/min |
Drill rod length | 3m |
Drill rod diameter | 76mm |
dimension | 5800*2040*3200 |
Climb ability | 25degree |
Walking speed | 2.5km/h |
Total weight | 8T |
Main volume system | |
Hoist force | 3400N |
Speed up | 50m/min |
Speed down | 96m/min |
Feed system | |
Axial pressure | 40820N |
Hoist force | 68040N |
Slow lift | 8m/min |
Slow forward | 16m/min |
