Mobile Water Well Drilling Rig(SLY600)

Technical Parameters and Specification

Drilling diameter (mm)

115--300

Drilling depth (m)

320

Work Pressure(Mpa)

1.0--3.0

Consumption (m³/min)

16--30

Drill pipe length (m)

3

Drill pipe diameter (mm)

89

Dimensions(mm)(L*H*W)

6300*2320*2780

Grade ability (°)

30

Footage efficiency(m/h)

5--30

Travelling speed(Km/h)

0--2.5

Total weight(t)

11.5

Feed Systems

Axle pressure (N)

57000

Lifting power (N)

80000

Rotary torque (Nm)

5200

Rotary speed

0--130

Host Power (Kw)

118
