Water Well Drilling Rig(SZ-200)

Water Well Drilling Rig(SZ-200) thumbnail-1
Water Well Drilling Rig(SZ-200) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other
Place of Origin:
Sichuan, China
Contact Supplier Request Quote Chat Now
Shandong Longye Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other
Place of Origin Sichuan, China
Brand Name longye
Model Number SZ-200
Usage Water Well

Specifications

SZ-200 hydraulic water well drilling rig,high air pressure hydraulic drilling rig

SZ-200 hydraulic water well drilling rig

SZ200 water well drilling rig have the character of light,high efficiency,multi-function.According to different conditions,it uses air,foam or slurry to rotate and drill.

Application:it is widely used in industrial and agriculture water project,drill water well,inspect well and other exploration borehole.which especially used for drilling geothermal heating stove.

 Technical parameter;

Bore diameter

127-254mm

Bore depth

213m

Work pressure

1.05-2.46Mpa

Air consumption

16-30m3/min

Drill rod length

3m

Drill rod diameter

76mm

dimension

5800*2040*3200

Climb ability

25degree

Walking speed

2.5km/h

Total weight

8T

Main volume system

Hoist force

3400N

Speed up

50m/min

Speed down

96m/min

Feed system

Axial pressure

40820N

Hoist force

68040N

Slow lift

8m/min

Slow forward

16m/min

Quick lift

26m/min

Quick forward

48m/min

Rotation torque

3200NM

Rotation speed

130r/min
