CTQ-Z138YA crawler blasting drilling rig ,uses new hydraulic technology,,with low air consumption ,large rotary torque,and easy for variable-bit-shift hole.Using Z138YA rig is reliable,high efficiency,when drilling in hard rock its speed is 2 times as fast as the low air pressuredrilling rig.It is mainly suitable for open mining ,water conservancy and other blasting hole projects.
Working pressure (Mpa) |
0.7-1.6 |
Air consumption(m3/min) |
10-15 |
Drilling diameter (mm) |
90-130 |
Drilling depth(m) |
level 40 down 30 |
Once promotion distance(mm) |
3000 |
Drill rod diameter(mm) |
60 |
Skid compensation(mm) |
900 |
Maximum lift force(N) |
24800 |
Skid pitch(.) |
up and down total 45 |
Swinging angle of skid(.) |
Left 40, right 30 |
Boom swing angle(.) |
Left 30, right 40 |
Boom Pitch(.) |
up and down total 60 |
Climb ability |
30 |
Chassis ground clearance(mm) |
260 |
Travelling speed(Km/h) |
0-2.5 |
Rotation speed(r/min) |
0-110 |
Rotary torque(N.m) |
2000 |
Host Power(KW) |
45 |
For rock |
f=6-20 |
Total Weight(Kg) |
4170 |
Dimension (L * W * H) |
5200*2030*2300 |
About ShanDong LongYe Machinary Co.,Ltd. is specialized in the production of hydraulic presure down-hole drilling rigs, engineering drills and water well drilling which are backbone enterprises.
