Product Details
| Brand Name | longye | Model Number | MZ130Y | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
spiral pile drilling machinedepth :30m
hole size:90-400mm
photovoltaic solar spiral pile drilling machine MZ130Y manufacturer
adopt new-style hydraulic technique ,large rotation torque.the structure of the drilling rig is compact, During drilling the slide-skid are support on the ground to ensure the drilling has good stability.The usage of MZ130Y drilling rig has realiable property Application:
MZ130Y crawler hydraulic drilling rig is mainly used in blasting hole of mining,photovoltaic solar spiral pile ,road building for exploring the stone and water well drilling.
Working pressure | 0.7-1.6Mpa |
Air consumption | 10-15m3/min |
Bore diameter | 90-400mm |
Bore depth | Horizontal 40 down 50 |
Feed stroke | 3000mm |
Drill rod diameter | 76mm |
Guide compensation | 900mm |
Lifting force | 24800N |
Guide pitch | Up and down 45degree |
Guide swing | Left 40 right30 |
Boom pitch | Up and down 60 degree |
Boom swing | Left 90 right45 |
Climb ability | 30 degree |
Ground clearance | 260mm |
Walking speed | 2.5km/h |
Rotation speed | 0-60r/min |
Rotation torque | 4600N.M |
Motor power | 55KW |
Total weight | 380000kg |
dimension | 4400*1900*2300 |
