1880mm fourdrinier and multi-cylinder culture paper machine
- 15 Set / Sets per Month
- Qingdao port
- T/T
Product Details
Condition: | New | Type: | Other, paper-making machine | Computerized: | No |
Place of Origin: | Henan, China | Brand Name: | Ginhua | Model Number: | 1880mm |
Voltage: | 380V | Power(W): | 540KW | Certification: | ISO |
Warranty: | 12months | After-sales Service Provided: | Engineers available to service machinery overseas | Weight: | 40-120gsm |
Packaging Details
robe straw ,wooden case
Product Description
1880mm fourdrinier and multi-cylinder culture paper machine
Main frame of equipments:
Fourdrinier part: The length of fourdrinier part is 12m, vacuum couch roll Φ650mm×2300mm open style headbox, inner is bordered with stainless steel, drave by two homogenate roll, macromolecule water board, macromolecule anti-grinding faceplate, suction box 6 pieces. Roll: none slot roll with rubber covered. Frame: square frame is made of steel.
Compression part: Φ700mm×2300mm natural marble stone roller 1 piece, Φ650mm×2300mm rubber roller 1 piece, Φ800mm×2300mm natural marble stone roller 2 pieces, Φ750mm×2300mm rubber roller 2 pieces, rubber hardness HSD 90°±2.
Dryer part: Φ1500mm×2300mm alloy dryer can 16 sets (4 sets 1500mm×2300mm chroming dryer cans). 1 set size press, arrangement: 10+size press+6. Pneumatic load device, rubber hardness HSD 90°±2, multi dryer part is equipped with fluctuate dryer mesh.
Calender and rewinding part: Three rolls calendar and cylinder type winding machine.
Driving and controlling part: Equipped with 500 reducer, motors with AC frequency convertor and adjustable speed, processing transmission.
Wheat straw pulping equipment:
Equipment |
Quantity |
Power |
25 m3 rotary spherical digester | 4 sets | 5.5 KW/Grade 4 |
Blowingout bin | 2 sets | 5.5 KW/Grade 4 |
18m conveyer | 1 set | 7.5 KW/Grade 4 |
5T Chaffcutter | 1 set | 22 KW/Grade 4 |
Dust catcher | 1 set |
|
Low consistency grit catcher 6 sets | 1 set |
|
Preimpregnation machine | 2 sets | 11 KW/Grade 4 |
220 horizontal type beating machine | 2 sets | 22 KW/Grade 4 |
35 m3 potcher | 4 sets | 11 KW/Grade 4 |
Paper making equipments list:
NO |
Equipments |
Qty(set) |
1 |
1880mm fourdrinier and multi-cylinder culture paper machine | 1 |
2 |
Size press | 1 |
3 |
Dryer can exhaust hood | 2 |
4 |
850 Axial ventilator | 2 |
5 |
SK-20 Water circle vacuum pump | 1 |
6 |
Suction box | 6 |
7 |
1800mm Winding machine | 1 |
8 |
Three roll calendar | 1 |
9 |
1880mm Rewinding machine | 1 |
10 |
3m3 High consistency hydrapulper | 1 |
11 |
1.2 m2 Inflow pressure screen | 1 |
12 |
1.8 m2 High frequency screen | 2 |
13 |
606 Desander 10 pcs | 1 |
14 |
IS250-200A Desander pump | 1 |
15 |
1.6 m2 Centrifugal screen | 1 |
16 |
Φ450 double disc refiner | 2 |
17 |
Φ750 Thruster | 6 |
18 |
Pulp pump-100 | 8 |
19 |
Pulp pump-150 | 4 |
20 |
Frequency conversion control cubicle | 1 |
21 |
Air pump cabinet | 1 |
22 |
Work table | 1 |
23 |
4T coal fire boiler | 1 |
We supply foundation drawing, assembly drawing, operation manual and related drawing for all equipments. We guarantee to offer the customer satisfied equipment and the machine would produce qualified product.
we will send our engineers and technicians to assist factory design, installation, commissioning and technical training
Company Profile
Gongyi Jinhua Machinery Manufacturing Co., Ltd. is a joint venture which mainly produces complete equipment of equipment of pulping and paper machine complete equipment,waste recycling plant,shredder machine,crusher machine,agricultural drying machine .
Our company is located in China's transportation hub in Zhengzhou city, founded in 1980. The production facility covers an area of 8,600 square meters with a construction area of 20,800 square meters. With the management idea of sincerity, after thirty years of continuous development and strength, now we employ over 500 full time staff members with more than 100 professional technicians. We also employ 50 staff members who are translators, salespersons, electronic commerce persons. Our company is an integrated industrial enterprise of scientific research, product development, manufacturing and sale.
Our company has modern management systems, advanced manufacturing technology, complete testing methods, a large number of excellent processing equipment and high-quality skilled workers. All products pass ISO9001:2008 international quality authentication. Our products are sold throughout the world, including Canada,America,South America,Gremany,France,England, Southeast Asia, Bangladesh, Indonesia, Pakistan, Egypt, Syria, Mexico, Nigeria, Russia, etc. Our company wins customers' trust and recognition widely with integrity, pragmatism, refinement development and eternal commitment.
Our company offers an exceptional service team of sale and technology, who offers program and craft process design, technical training and so on. We also offer service of pre-sales, in-sales and after-sales.
