1575mm 10-15T/D Double-dryer and Double-mould Corrugated/Kraft Paper Machine
Sample Machine:
Features:
1. customer-oriented design principle
2. high rate of output with high quality
3. mature skills and technology support
4. considerate pre-sales and after-sales service
5. appropriate discount can be negotiated
Main Equipment Parts:
Part name |
Equipment |
Specification |
Quantity |
|
Mesh cylinder Part
|
cylinder mould (stainless steel) |
1250×1950mm |
2 |
couch press |
400mm×1950mm |
2 |
|
reverse press |
400mm×1950mm |
1 |
|
Shore hardness |
38o±2 |
||
Press part |
stone roll |
500×1950mm |
1 |
rubber roll |
450×1950mm |
1 |
|
Shore hardness is 90o±2, pneumatic loaded equipment . | |||
Dryer part |
dryer can |
2500mm×1950mm |
2 |
touch roll |
450mm×1950mm |
1 |
|
riding roll |
400mm×1950mm |
1 |
|
Pneumatic loaded equipment, and the second dryer is equipped with dry wire | |||
Winger roll |
casting iron roll |
260mm×1950mm |
1 |
top rubber roll |
1 |
||
Mechanical pressure equipment | |||
Felt roll |
felt roll |
159mm×1950mm |
28 |
Equipment List
No |
Equipment |
Qty |
1 |
1575mm double-cylinder& double –mold paper machine |
1 set |
2 |
Exhaust hood of dryer can |
1 set |
3 |
Screw type ventilator |
1 set |
4 |
15 type roots pump |
1 set |
5 |
suction box |
3 sets |
6 |
5m3 hydrapulper |
1 set |
7 |
1.8m2 High frequency vibrating screen |
1 set |
8 |
380 Double disks refiner |
2 sets |
9 |
12m2 Decker thickener |
1 set |
10 |
0.9m2Centriscreen |
1 set |
11 |
Pulp pump |
4sets |
12 |
Pulp pump |
2 sets |
13 |
700Thruster |
3 sets |
14 |
1575 winding machine |
1 set |
15 |
three roll calender |
1 set |
16 |
1575 Rewinding machine |
1 set |
Pre-sales Service:
- offer technical problems consultation
- visit our factory to see finished machines
- optimize the sheme to lower your investment
- negotiate for an appropriate discount
- take equipments quality test before delivery
- offer fast and safe delivery
- assist to establish production line
- send engineers to install and debug equipment
- train first-line operators on site
- regularly visit to help solve production problems
- provide life-long maintenance service
