SunNav Receiver With Hemisphere P307 Gps Motherboard Inside

High precision GNSS OEM board, GPS mother board, GPS chip,GPS module

GPS module Hemisphere P307

Signal tracking:
   GPS: L1C / A, L2C, L5
   GLONASS: L1 C / A, L1P, L2 C / A, L2P
   BDS: B1, B2, B3
   SBAS: L1 C / A, L5 supports WASS, EGNOS and MSAS
   Galileo Galileo GIOVE-A and GIOVE-B are reserved
Accuracy:
   Static Accuracy:
         Plane accuracy: ± 2.5mm + 1ppm
         Elevation accuracy: ± 5mm + 1ppm
   RTK Accuracy:
         Plane accuracy: ± 1cm + 1ppm
         Elevation accuracy: ± 2cm + 1ppm
   Code Differential positioning accuracy: 0.25 ~ 0.45m (CEP)
   Stand-alone positioning accuracy: 1.5m (CEP)
   Speed measurement accuracy: 0.01m / s
Signal tracking:
   Cold start time <50s
   Warm start time <30s
   Hot start time <15s
   Signal Recapture: <2s
   RTK initialization time: <10s
   Initialization Reliability: Typical> 99.9%
ELECTRICAL PARAMETERS
   Power consumption: ≤ 3.0W
   Power supply voltage: DC 6 ~ 28V, with positive and negative reverse polarity protection
Physical properties
   Operating temperature: -40 ℃ ~ +70 ℃
   Storage temperature: -45 ℃ ~ +80 ℃
   Physical Dimensions: 136mm X 89mm
   Weight: 0.7Kg
   Protection class: IP67
   Impact and Vibration: Anti-2m drop
   Indicator: 6 LED indicators
Data interface:
   Data output: NMEA-0183, raw data
   Data refresh rate: 1 - 50Hz optional
   Differential format: RTCM2.3 / 3.0 / 3.1 / 3.2, CMR, RTCA
   Communication: radio communication module or GPRS / 3G module (CORS)
   Interface: 9 core air connector
   Power supply: 2
   Baud rate: 9600-115200
   Serial port: one
   Data link antenna: one
