SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board

Tianjin Jinfeng Surveying Instrument Co., Ltd.
SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board thumbnail-1
SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board thumbnail-2
SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board thumbnail-3
SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board photo-1
SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board photo-2
SunNav K100G Gps GNSS Receiver Module OEM Board GPS Board GNSS Board photo-3
US$ 0.01 - 0.1 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Other, GNSS Board
Use:
Other, Land Survey, Machine Control, Robot, GPS
Screen Size:
Other, none
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, GNSS Board
Use Other, Land Survey, Machine Control, Robot, GPS
Screen Size Other, none
Function Other, Development Board
Place of Origin Tianjin, China
Brand Name SunNav
Model Number K100G
Warranty 12 Months

GNSS Board K501G



SunNav K100G gps GNSS Receiver Module OEM Board GPS Board GNSS Board





Specifications

Signal Tracking
 Channel 120 Channels
 GPS L1 C/A Code, L1/L2 P Code
 GLONASS L1, L2
 SBAS WAAS, EGNOS, MSAS
 Cold Start < 50s
 Warm Start < 30s
 Hot Start < 15s
 Signal Reacquisition < 2s
 Positioning Specifications
 Pseudo Range AccuracyGPS L1=10cm/L2 =10cm, GLONASS L1=10cm/L2=10cm
 Carrier Phase AccuracyGPS L1=0.5mm/L2=1mm, GLONASS L1=1mm/L2=1mm
 Standalone Position Accuracy < 1.5m
 Real Time Kinematics (RTK) Horizontal: 10 mm + 1 ppm RMS
  Vertical: 20 mm + 1 ppm RMS
 Initialization Time Typically < 10s
 Initialization Reliability Typically > 99.9%
 Post Processing Static Horizontal: 2.5 mm + 1 ppm RMS
  Vertical: 5 mm + 1 ppm RMS
 Velocity Accuracy 0.03 m/s
 Acceleration 4g
 Overload 15g
 Time Precision
 GPS 20 ns
 GPS + GLONASS 20 ns
 Communications
 RS232 3 LV-TTL Ports, Baud rates up to 921,600 bps
 Positioning Data Outputs 1 Hz, 5 Hz & 10 Hz (depends on installed option)
 Raw Data Outputs 1 Hz, 5 Hz, 10Hz & 20 Hz
 PPS 1 Pulse Per Second Output
 Indicating Light 3 LED Indicating light
  Indicating Power, Satellite Tracking and Differential Data
 Data Format
 Correction Data I/O RTCM 2.1, 2.2, 2.3, 3.0, 3.1, CMR(GPS only),CMR+(GPS only)
 Position Data Outputs ASCII: NMEA-0183 GSV, RMC, HDT, VHD, GGA, GSA, ZDA,
             VTG, GST, PJK, PTNL
  Extended NMEA-0183 BDGGA, GPNTR, GPCDT, GPHPR
  Binary (compatible with major brands)
 Phisical
 Size (L x W x H) 71mm x 46mm x 11mm
 I/O Interface 20-pin Double Male Header
 Weight 26g
 Antenna 1 x MCX Receptacle (10 MHZ)
 Environmental
 Working Temperature -40°C to +85°C
 Storage Temperature -55°C to +95°C
 Humidity 95% Non-Condensation
 Electric
 Input Voltage 3.3-6V DC
 Power Consumption 1.0W
 Memory 100MB



Our Services

  Payment And Delivery:



 Warranty Period:

12 months after the delivery time from our factory.



After Sale Service:

After Sale, We provide free technical support via e-mail, skype chatting, telephone or video if necessary. Or you could also dispatch your engineers to our company, we can offer free training face to face. You should please bear the air tickets and all costs when staying in China. We offer additional accessories if you need. But the additional accessories will be charged.
