Home > Products > Hydraulic Tee Forming Machine > Tee Forming Machine
Tee Forming Machine
- SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | MINGHENG | |
| Model Number | YSLT100A | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Our machine is designed for manufacturing both equal and unequal with diameter from 1/2”to 32 of stainless steel ,carbon steel,alloy steel and some kinds of copper steel.It has individual power construction and electrical system,adopts PLC button centralized control and programmed touch screen operation system to realize four kinds of operation methods:inching,manual,semi-automatic and full automatic.the application of advanced control system makes the flow and pressure date to be adjusted automatically to achieve safe operation and better quality.our machines has the advantage of raw material saving and enery saving.
Main features:
1.It is constructed with strong metal frame with good apearence and stable functioning.
2.It has individual power construction and electrical system,adopts reliable PLC button centralized control, use programmed touch screen operation system, apply proportional valve to regulate pressure, it will pressurized in curve, which can be conveniently adjusted and operated both manually and automatically.
3. Our specical designing could reduce the blank size of raw material.
| Model | YSLT100A | YSLT150B | YSLT200A | YSLT300B | YSLT400A | YSLT500B | YSLT600A | YSLT700B |
| forming size range (inch) | 1/2''-4 | 2''-6'' | 2''-8'' | 5''-12'' | 6''-16'' | 8''-20'' | 10''-24'' | 12''-28'' |
| mould lock power (KN) | 5000 | 8000 | 12500 | 22000 | 25000 | 35000 | 45000 | 60000 |
| mould lock stroke (mm) | 450 | 500 | 600 | 800 | 1000 | 1200 | 1300 | 16500 |
| side pushing stroke (mm) | 200 | 250 | 300 | 400 | 450 | 500 | 600 | 700 |
| ejector force (KN) | 500 | 1000 | 1500 | 2000 | 2500 | 3150 | 4000 | 5000 |
| stroke of demoulding (mm) | 100 | 150 | 200 | 250 | 300 | 600 | 650 | 850 |
| work table size (mm) | 700*700 | 1000*1000 | 1100*1100 | 1200*1500 | 1400*1800 | 1800*1800 | 2000*2000 | 2200*2500 |
| enriching power (Mpa) | 300 | 250 | 200 | 200 | 200 | 160 | 160 | 160 |
| max working pressure (Mpa) | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| general power (KW) | 55 | 70 | 110 | 276 | 295 | 350 | 400 | 580 |
| side pushing power (KN) | 4500X2 | 7000X2 | 11000X2 | 18000X2 | 22000X2 | 30000X2 | 40000X2 | 55000X2 |
