Tee Cold Forming Machine

Tee Cold Forming Machine thumbnail-1
Tee Cold Forming Machine photo-1
US$ 50,000 - 850,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
MINGHENG
Contact Supplier Request Quote Chat Now
Shanghai Mingheng Pipe Fittings Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name MINGHENG
Model Number YSLT100A
Automation Automatic
Certification Other, CE and ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Tee press machine of model YSLT100A could be used for manufacturing tees size ranging from 1/2" to 4" manually or automatically.

Tee Elbow cold forming machine of model YSLT100A could be designed and manufactured for manufacturing equal and reducing tees of sie from 1/2" to 4" with thickness from SCH10 to XXS of stainless steel, carbon steel, alloy steel, monel, nickel alloy,  but the normal model just will be designed and manufacured for manufacturing maximum thickness up to SCH80



Main features:

1.It is constructed with strong metal frame with good apearence and stable functioning.



2.It has individual power construction and electrical system,adopts reliable PLC button centralized control, use programmed touch screen operation system, apply proportional valve to regulate pressure, it will pressurized in curve, which can be conveniently adjusted and operated both manually and automatically.



3. Our specical designing could reduce the blank size of raw material.

Model YSLT100A YSLT150B YSLT200A YSLT300B YSLT400A YSLT500B YSLT600A YSLT700B
forming size range (inch) 1/2''-4 2''-6'' 2''-8'' 5''-12'' 6''-16'' 8''-20'' 10''-24'' 12''-28''
mould lock power (KN) 5000 8000 12500 22000 25000 35000 45000 60000
mould lock stroke (mm) 450 500 600 800 1000 1200 1300 16500
side pushing stroke (mm) 200 250 300 400 450 500 600 700
ejector force (KN) 500 1000 1500 2000 2500 3150 4000 5000
stroke of demoulding (mm) 100 150 200 250 300 600 650 850
work table size (mm) 700*700 1000*1000 1100*1100 1200*1500 1400*1800 1800*1800 2000*2000 2200*2500
enriching power (Mpa) 300 250 200 200 200 160 160 160
max working pressure (Mpa) 25 25 25 25 25 25 25 25
general power (KW) 55 70 110 276 295 350 400 580
side pushing power (KN) 4500X2 7000X2 11000X2 18000X2 22000X2 30000X2 40000X2 55000X2

tee cold forming machinetee cold forming machine
