elbow cold forming machine
- 30 Set / Sets per Month
- SHANGHAI
- T/T
- 10mm hot press brake bending machine for brake pad
- Custom bending press brake and shearing machine
- Square steel tube press brake machine for making gutters
- CNC hydraulic press brake steel bar cutting and bending machine
- Crank type bending machine heavy duty press brake 125t 3200
- 6 axes cnc press brake machine hydraulic for making gutters ceramic
Product Details
Condition: | New | Brand Name: | MINGHENG | Model Number: | YLT400A |
Machine Type: | Pipe and Tube Bending Machine | Raw Material: | Other, welded and seamless pipes | Material / Metal Processed: | Other, stainless steel, carbon steel, alloy steel, alunimium, copper, nickel |
Power: | Hydraulic | Automation: | Other, automatically and manually | Extra Services: | End Forming |
Certification: | Other, CE and ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.manufacture the elbows range from 1/2''-32'' with thickness from Sch20--Sch802.adopt PLC button centralized control
Elbow Cold Forming Machines of YLT series are designed and constructed not only for manufacturing the small radius (1.0D-1.5D) standard stainless steel elbow, but also for the carbon steel, alloy steel, nickel alloy, copper elbows, etc
The specification (dimension, radius, thickness) of the finished products can meet the stipulated international standard, such as ANSI B16.9, ANSI B16.28, DIN2605, JIS, GOST, SMS, 3A, ISO, etc, The machines are fit for the batch production
It is constructed with strong mental frame with good appearance and stable functioning.
It has individual power construction and electrical system, adopts PLC button centralized control and programmed touch screen operation system, which can be convenient adjusted and operated both manually and automatically
It has special demoulding devices and mould orientation device which makes the mould change easy
It has the features of energy saving, easy operation, high quality for products compare to hot forming process
YLT65A | YLT100B | YLT150B | YLT200A | YLT300B | YLT400A | YLT500B | YLT600A | YLT700A | YLT800A | ||
forming size range (inch) | 1/2'' - 3'' | 1/2'' - 4'' | 2'' - 6'' | 4'' - 8'' | 5'' - 12'' | 8'' - 16'' | 12'' - 20'' | 12'' - 24'' | 18'' - 28'' | 20'' - 32'' | |
Max mould lock power (KN) | 800 | 1200 | 2000 | 3150 | 5000 | 10000 | 15000 | 20000 | 25000 | 35000 | |
side pushing power (KN) | 630 | 1000 | 1500 | 2000 | 3500 | 5600 | 8000 | 10000 | 12500 | 15000 | |
working pressure (Map) | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
processing speed (SEC/PCS) | 10-40 | 35-70 | 50-90 | 70-110 | 120-250 | 200-360 | 300-600 | 350-720 | 400-900 | 500-1200 | |
General Power (KW) | 11 | 15 | 18.5 | 22 | 37 | 60 | 90 | 120 | 145 | 190 | |
weight (T) | 4.5 | 6.5 | 22 | 28 | 42 | 75 | 180 | 280 | 320 | 520 |
