USD7,900 cheap impact crusher (50tph) for Mozambique market
- 300 Set / Sets per Month
- Shanghai/Qingdao
- T/T L/C D/P D/A Credit Card PayPal
- 7,900USD high capacity 50Ton basalt impact crusher 1000USD after discout sell to Morocco country
- USD7900 impact crusher promotion price to Niger customer to crush granite
- special offer Nigeria customer USD7,900 limestone basalt impact crusher (50T per hour)
- Jaw plates crusher and crusher spare parts
- PE250*400 jaw plate crusher spare parts large quantity wholesale
- Jaw crusher factory supply spare parts jaw plate, toggle plate,fly wheel
Product Details
Condition: | New | Type: | Impact Crusher | Application: | Quarry, highway construction industry |
Motor Type: | AC Motor | Power(W): | 160KW | Capacity(t/h): | 180T/H |
Place of Origin: | Henan, China | Brand Name: | YIGONG | Model Number: | PF |
Dimension(L*W*H): | 2.6*2.7*2.9m | Weight: | 18.5t | Certification: | BV &SGS |
Warranty: | 1 YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
impact crusher Main equipment adopts nude package, easy to lose, damped, damage, broken ones will be paked in wood crate or composite board crate.
Customer need: we will satisfy what kind of package style customer need.
Product Description
USD7,900 cheap impact crusher (50tph) for Mozambique market
Brief introduction of impact crusher
Impact crushers is widely used as secondary stone crusher in quarrying, mining, metallurgy, building and construction materials industries....
Based on "rock on rock" and with three crushing chambers, the final products is with cubic shape, "PENGSHENG" impact crusher is especially suiltable for making aggregates used in highway construction.
Features of Impact crusher
1.Connected with locking sleeve assembly.
2.Final product with cubical shape.
3.The blow bar with high chrome.
4.Easy maintenance. Hydraulic or hand opening.
5.High reduction ratio and crushing efficiency;
Main parts of impact crusher
Impact crusher is mianly made by frame, main shaft, rotor, blow hammer, impact rack, impact liner, protection liner, flywheel, feed opening, discharge opening...
Working principle of Impact Crusher :
When the impact crusher works, the motor drives the rotor rotate with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being recrushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then discharged from outlet.
Impact crusher
Technique Parameter:
Type | Max Feed Size(mm) | Capacity(t/h) | Motor Power(kw) | Weight(t) | Overall |
PF-0504 | 100 | 4-8 | 7.5 | 1500 | 1425×1570×1011 |
PF-0506 | 150 | 10---20 | 22 | 2870 | 1460×1590×1380 |
PF-0607 | 150 | 15-25 | 30 | 4000 | 1480×1620×1570 |
PF-0705 | 200 | 20-30 | 30 | 4635 | 1560×1440×1590 |
PF-0807 | 300 | 20-35 | 37 | 5400 | 1980×1560×1670 |
PF-1007 | 250 | 30-50 | 37 | 6500 | 2235×1776×1860 |
PF-1010 | 300 | 50-70 | 55 | 11000 | 2320×2255×1624 |
PF-1013 | 300 | 80-120 | 90 | 12000 | 1830×2500×1840 |
PF-1210 | 350 | 70-120 | 110 | 16200 | 3357×2255×2466 |
PF-1214 | 350 | 130-180 | 132 | 18579 | 2700×2700×2900 |
PF-1315 | 500 | 160-250 | 200 | 19000 | 2750×2720×2930 |
PF-1320 | 500 | 300-375 | 315 | 24000 | 2780×2760×2960 |
PF-1416 | 600 | 280-320 | 280 | 28500 | 2800×2350×2690 |
PF-1622 | 800 | 500-600 | 450 | 92000 | 2900×2950×2760 |
PF-1822 | 1000 | 650-800 | 560 | 106500 | 3400×3160×2980 |
2PF-1010 | 450 | 50-70 | 55 | 23000 | 4800×3385×3180 |
75 | |||||
2PF-1212 | 700 | 80-150 | 75 | 64000 | 5200×3900×4065 |
90 | |||||
2PF-1416 | 800 | 100-200 | 132 | 110000 | 5580×4430×4950 |
160 |
front
back
hydrualic oil pump
rotor
output hopper
liner
foundation bolt
...
Company Profile
Henan Yigong Machinery & Equipment Co., Ltd. is a manufacturer specialize in building material equipment, mining machines, stone plant equipments,etc. that is founded in 2008 by restructuring. The firster company was established in 1978. Now, We integrate the research, development, production, and sale together. Our company is located in Zhengzhou City which is a transportation junction city of China. After 30 years' development, our company has already owed 3 branch companies and 1 machinery research institute. Our company covers an area of 50,000 square meters, including 15,000 square meters of modern buildings. We have adopted the scientific management mode of modern enterprises, and constantly strived to create novel products. As a result, our company has become a famous enterprise of machinery industry in China.
With many years' development, we have accumulated rich experience in the production and management, and brought up a large number of technical members and management elites. Nowadays, we have 660 employees, including 180 senior and intermediate technical members. Through constant introduction, digestion and absorption, our company has 100 sets of various large and medium equipment and several workshops for casting, forging, thermal treatment, machinery processing, welding, assembly, and machine repair. The maximum capability of assembly lift is 120MT. Our company has passed the evaluation of ISO9001.2000 certification. We constantly renew products, which are well-known around the world and well-accepted by customers.
Our main products include five series, such as aerated concrete equipment, lime-sand brick and autoclaved ash brick equipment, sandstone making equipment, metallurgy and mineral processing equipment and crushing equipment. They can be divided into 30-odd kinds and 100-odd types. These equipment are widely used in building-material, metallurgy, corhart, and ceramic industries.
Welcome to visit our web site : www.enyigong.com and contact us to know more information about our product.
