after discount 9,700USD complete set impact crusher stone crusher for Kenya customer
- 300 Set / Sets per Month
- Shanghai/Qingdao
- T/T L/C D/P D/A Credit Card PayPal
- 7900USD crusher 50T crusher impact crusher send to Liberia
- 50T stone impact crusher limestone crusher for Libya end user(USD7,900)
- USD7,900 stone crusher 50T impact crusher for Libya end user
- Lesotho country popular use 7,900USD Granite impact crusher PF1008
- USD7,900 Industrial impact crusher Granite crusher for Malawi customer
- PF1008 50t impact crusher great discount sell to Mali customer (7,900USD)
Product Details
Condition: | New | Type: | Impact Crusher | Application: | Quarry, highway construction industry |
Motor Type: | AC Motor | Power(W): | 160KW | Capacity(t/h): | 180T/H |
Place of Origin: | Henan, China | Brand Name: | YIGONG | Model Number: | PF |
Dimension(L*W*H): | 2.6*2.7*2.9m | Weight: | 18.5t | Certification: | BV &SGS |
Warranty: | 1 YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
impact crusher Main equipment adopts nude package, easy to lose, damped, damage, broken ones will be paked in wood crate or composite board crate.
Customer need: we will satisfy what kind of package style customer need.
Product Description
after discount 9,700USD complete set impact crusher stone crusher for Kenya customer
Brief introduction of impact crusher
Impact crushers is widely used as secondary stone crusher in quarrying, mining, metallurgy, building and construction materials industries....
Based on "rock on rock" and with three crushing chambers, the final products is with cubic shape, "PENGSHENG" impact crusher is especially suiltable for making aggregates used in highway construction.
Features of Impact crusher
1.Connected with locking sleeve assembly.
2.Final product with cubical shape.
3.The blow bar with high chrome.
4.Easy maintenance. Hydraulic or hand opening.
5.High reduction ratio and crushing efficiency;
Main parts of impact crusher
Impact crusher is mianly made by frame, main shaft, rotor, blow hammer, impact rack, impact liner, protection liner, flywheel, feed opening, discharge opening...
Working principle of Impact Crusher :
When the impact crusher works, the motor drives the rotor rotate with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being recrushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then discharged from outlet.
Impact crusher
Technique Parameter:
Type | Max Feed Size(mm) | Capacity(t/h) | Motor Power(kw) | Weight(t) | Overall |
PF-0504 | 100 | 4-8 | 7.5 | 1500 | 1425×1570×1011 |
PF-0506 | 150 | 10---20 | 22 | 2870 | 1460×1590×1380 |
PF-0607 | 150 | 15-25 | 30 | 4000 | 1480×1620×1570 |
PF-0705 | 200 | 20-30 | 30 | 4635 | 1560×1440×1590 |
PF-0807 | 300 | 20-35 | 37 | 5400 | 1980×1560×1670 |
PF-1007 | 250 | 30-50 | 37 | 6500 | 2235×1776×1860 |
PF-1010 | 300 | 50-70 | 55 | 11000 | 2320×2255×1624 |
PF-1013 | 300 | 80-120 | 90 | 12000 | 1830×2500×1840 |
PF-1210 | 350 | 70-120 | 110 | 16200 | 3357×2255×2466 |
PF-1214 | 350 | 130-180 | 132 | 18579 | 2700×2700×2900 |
PF-1315 | 500 | 160-250 | 200 | 19000 | 2750×2720×2930 |
PF-1320 | 500 | 300-375 | 315 | 24000 | 2780×2760×2960 |
PF-1416 | 600 | 280-320 | 280 | 28500 | 2800×2350×2690 |
PF-1622 | 800 | 500-600 | 450 | 92000 | 2900×2950×2760 |
PF-1822 | 1000 | 650-800 | 560 | 106500 | 3400×3160×2980 |
2PF-1010 | 450 | 50-70 | 55 | 23000 | 4800×3385×3180 |
75 | |||||
2PF-1212 | 700 | 80-150 | 75 | 64000 | 5200×3900×4065 |
90 | |||||
2PF-1416 | 800 | 100-200 | 132 | 110000 | 5580×4430×4950 |
160 |
front
back
hydrualic oil pump
rotor
output hopper
liner
foundation bolt
...
