Large capacity charcoal hydraulic charcoal briquette press machine supplier
1.Production description of charcoal briquette ball press machine
Charcoal briquette machine is mainly used to suppress charcoal powder, toner, coke toner,bamboo carbon powder, the hookah carbon, graphite, page shell carbon, Jujube carbon, blue toner, such as activated carbon etc, kinds of powder materials, powder, waste. It can press materials into square, ball egg-shaped, round, oval, and round column, bread type, pillow type and other special shapes. Charcoal powder briquette machine is widely used in refractory, power plants, metallurgy, chemical industry, energy, transportation, heating, animal husbandry, industry, agriculture, barbecue and other fields. This machine not only is suitable for single operations and large-scale briquette production line, but also can adapt to mobility operations.
2.The Raw material of charcoal briquette ball press machine
3.Charcoal briquette ball press machine Working principle
This series of briquette machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
4.Characteristics of charcoal briquette ball press machine
1.Advanced technology briquettiong machine line;
2.High briquetting ratio and pressure
3.High pressure coal briquetting machine line.
4. With our self researched formula, the briquette is smokeless,.high density and easy to be ignited.
5.Offer installation guide or installation overseas. And Different design according to your place and raw mateiral.
6. Spline structures and fully enclosed gear reducer make sure our machines accurate pointing, Rational structure, smooth operation, low voice, energy saving.
5.Charcoal briquette ball press machine parameters:
Type | Capacity (t/h) | Roll Diameter (mm) | Pressure(t) | Roll Speed (r/min) | Power (kw) | Reducer |
|
|
|
|
|
|
|
MC-290 | 1.5-2 | 290 | 18-20 | 15-17 | 5.5 | ZQ290 |
MC -360 | 2.5-3.5 | 360 | 20 | 15-17 | 7.5 | ZQ360 |
MC -400 | 4-5 | 400 | 22 | 15-17 | 11 | ZQ400 |
MC-500(1) | 6-8 | 370 | 24 | 15 | 15 | ZQ500 |
MC-500(2) | 8-10 | 500 | 25 | 15 | 22 | ZQ650 |
MC -650 | 10-15 | 650 | 30 | 15 | 30 | ZQ650 |
MC -750 | 15-20 | 750 | 34 | 13 | 30 | ZQ750 |
MC -850 | 25-30 | 850 | 54 | 13 | 37-45 | ZQ850 |
MC 1000(1) | 35-40 | 1000 | 60 | 12 | 45-75 | ZSY-355 |
MC 1000(2) | 35-45 | 1000 | 77-240 | 10 | 75-90 | ZSY-400 |
Shape and size of final briquettes: square, ball egg-shaped, round, oval, and column, strip-type, elliptic type, pillow type and other special shapes by customizing the matching molds. Usurally 20-60mm. | ||||||
6.Pre-sale service,Installation and After sales service
The Pre-sale service is free, begins with analyzing and planning of your particular needs. Whether you need a single machine, a multi-stage process? Or a production line of complete plant. Henan Machine Co.,Ltd.can advise you on the right solution for the most cost-efficient briquetting.
We can guide you to install the products or directly send our engineer in your country for the installation.
In the after sales service, Henan Machine Co.,Ltd. has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts. Spare and wear parts are always close to you.
7.Payment,Packing and Delivery
1. Payment :30% TT in advance, 70%TT balance pay off before delivery.
2. Packing: The machine and wear parts will protected by plywooden box or as customers’ will
3. Delivery time: For one set, the delivery time is 7-10 days, for 1-5 sets 20-25 days, above 5 sets usually negotiate.
Thanks for your interest in our machines and please contact us freely if you have any questions ot requirements by the following contact information. Your visit of our factory to test the machines you like will be warmly welcomed. Hope to have have the honor to cooperate with you in the bright future.
