Excellent recycling technologies automatic operation waste engine oil distillation plant

FOB Price

US$ 40,000 - 70,000 / Set

1 Set(Min. Order)

Port lianyungang
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China		Brand Name	DYJD
Model Number	DYZL-10

Product Description

Excellent recycling technologies automatic operation waste engine oil distillation plant

1.Welcome to our company

2. 3D Work flow chat of Waste Diesel Recycling Distillation Plant

Product name: Excellent recycling technologies automatic operation waste engine oil distillation plant : Recycling waste oil to diesel oil

Technology: Waste to energy using pyrolysis technology

Features

NO.	Raw Material	Note
1	Waste engine oil	All kinds of liquid oil will be ok, Just the oil yield is different, Please tell us your raw material, our engineer can test the oil yield for you before make order.
2	Tyre oil
3	Plastic oil
4	Waste crude oil
5	All kinds of fuel oil
6	All kinds of heavy oil
7	lubricating oi

3 .Technical Parameter For Waste Diesel Recycling Distillation Plant

Distillation reactor

Type	Technical parameter
Type	Steel thickness(mm)	daily disposal(T)	daily power(°C)	daily water(m3)	daily coal(kg)
8m3/5T	12	5	80	0.5	500-600
12m3/8T	12	8	120	0.8	700-900
15m3/10T	16	10	180	1.5	1200-1400
30m3/20T	16	20	280	2.5	1500-1600

Catalyst tower

Type	Technical parameter
Type	thickness of tower(mm)	dia. of tower(φ)	high of tower(mm)	tray quantity of tower(layer)
8m3/5T	6	600	2800	3
12m3/8T	8	700	3600	3
15m3/10T	10	800	3800	4
30m3/20T	10	800	4600	4

4.Main specification Of Waste Diesel Recycling Distillation Plant

Model	Reactor material	Capacity	Container
DYZL-05	316L stainless steel	3-5tons	2*40HQ
DYZL-10	316L stainless steel	6-10tons	2*40HQ
DYZL-15	316L stainless steel	10-15tons	2*40HQ
DYZL-20	316L stainless steel	15-20tons	3*40HQ
DYZL-25	316L stainless steel	20-25tons	3*40HQ
DYZL-30	316L stainless steel	25-30tons	4*40HQ

5. Waste Diesel Recycling Distillation Plant Features

1.This continuous oil distillaiton plant can working continuous non-stop for about 30 Days

2.The whole system have pre-heating system, this system use exhaust gas (produced by coal or wood burining to heat distillaiton plant )to heating raw oil before raw oil go into distillaiton reactor. This preaheating sytem can save fuel in great degree and saving heating time .

3.This continuous oil distillaiton plant is environmental protection.

The plant have advance dedust and desulfer system ,wich can keep the smoke go into sky non-polution.

4. This continuous oil distillaiton plant is safety

a. There is safety vavles on the plant

b. There is auto alarming sytem ont he plant

c. There is electric control system on the plant
