The cheapest automatic welding machine price
Specification
Mode |
FH18-90ZD |
Linear rate of welding |
6-21m/min |
Production capability |
15~38Cans/min |
Applicable can diameter |
Φ220~Φ300mm |
Applicable can height |
250~450mm |
Applicable material |
Tinplate steel-based |
Applicable material thickness |
0.25~0.42mm |
Seam welding landing |
0.8mm 1.0mm 1.2mm |
Seam point distance |
0.5-0.8mm |
Applicable copper wire diameter |
1.5mm 1.7mm |
Cooling water |
Temperature 12~18°C Pressure:0.4-0.5Mpa Discharge 12L/min |
Compressed air consumption |
400 L/min |
Pressure of compressed air |
0.5Mpa-0.7Mpa |
Power |
380V±5% 50HZ |
Total power |
63KVA |
Packed Dimension |
2300x1800x2000mm |
Packed Weight |
2500Kg |
Features
1. PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.
2. Low voltage apparatus are produced by SCHNEIDER.
3. IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.
4. OMRON is our sensor supplier.
5. HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.
Can making technology process
Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling
Applicable types of cans
aerosol can ,food cans,beverage can ,round can,quadrate bucket etc.
