KD Rotary Vane Vacuum Pump/Portable Vacumm Pump
Features
1. The 2XZ series rotary vane type vacuum pump belongs to two stage direct connection structure rotary vane vacuum pump, which can be used for drying, sealing the container and other ancillary pumping air or net vacuum equipments.
2. It has the advantages of small size, light weight, low noise, convenient for using and more.
3. The 2XZ series rotary vane type vacuum pump can not be used as the compression type delivery pump.
Detailed description
2XZ series rotary vane type vacuum pump can be used independently, which also can be as Booster pump, Diffusion pump, Molecular pump and Titanium Pump's pre-pump. Also used as electronic devices produce, vacuum drying , filtration , welding, metal smelting etc .
Technical data
Model |
2XZ-0.5 |
2XZ-1 |
2XZ-2 |
2XZ-4 |
2XZ-8 |
2XZ-15 |
|
Pumping speed (L/S) |
0.5 |
1 |
2 |
4 |
8 |
15 |
|
Ult. vacuum (Pa) |
Without gas ballast |
≤6*10-2 |
|||||
With gas ballast |
≤6.5 |
≤1.33 |
|||||
Rotary speed (r/min) |
1400 |
1410 |
1410 |
||||
Working Voltage (V) |
220 |
220/380 |
|||||
Motor power (Kw) |
0.18 |
0.25 |
0.37 |
0.55 |
1.1 |
1.5 |
|
Inlet diameter (mm) |
Φ16 |
Φ16 |
Φ25 |
Φ25 |
Φ40 |
Φ40 |
|
Temp. rise of pump oil (℃) |
40 |
≥45 |
≥65 |
≥70 |
|||
Oil capacity (L) |
0.5 |
0.55 |
0.8 |
0.1 |
2.5 |
4.0 |
|
Size |
L (mm) |
445 |
467 |
488 |
528 |
575 |
703 |
W (mm) |
130 |
130 |
145 |
145 |
172 |
338 |
|
H (mm) |
254 |
254 |
280 |
280 |
350 |
453 |
|
|
Weight (kg) (with 3-phase motor) |
13.5 |
15 |
20 |
23 |
48.5 |
77.5 |
|
Noise (db) |
≥60 |
||||||
Vibration reference number (u) |
≥80 |
||||||
♦The rotary vane vacuum pump is not only the ancillary equipment of the vacuum drying oven, but also widely used in laboratory.
Packaging
-Plywood or cartons packaging
-Both neutral and customized packaging can be available.
Shipping
-We can ship the goods to you by International Express such as DHL, TNT, EMS, FedEX and so on and you can also choose the appropriate one based on your timeline and budget. Besides, you can definitely choose to use your own shipping agent.
Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd.
Our company always adheres to the "quality casting brand, professional achieves service"
business philosophy, and the main product is rotary evaporator, short path distillation, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, rotary vane vacuum pump, low temperature cooling fluid circulating pump(cooling chiller), vacuum drying oven, blast drying oven, high-pressure reaction kettle, microwave chemical reactor, freeze dryer, water/oil bath, magnetic heating stirrer, hydrothermal synthesis reactor, heating mantle, lift jack, etc. Besides, we act as agents of some domestic and foreign famous enterprise products, sustaining high prais in domestic junior colleges and universities, scientific research units, etc. Our products are sold to USA, Australia, Asia, Brazil, Iran, Egypt etc.
The quality of the products, also full affirmation and praise by our domestic and foreign customers.
Business Type: Manufacturer, Trading Company.
Location: Henan, China (Mainland).
Year Established: 2009.
Total Revenue : US$1 Million - US$2.5 Million.
Registration No: 410105000067362.
Main Markets: Central America, Mid East, Oceania, Africa, South America and so on.
1. Pre-service
24 Hours online service for your consult.
Help choose right model and a series of service, person advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convenient.
--Promptly production and delivery, inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Engineer are available for oversea training.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
4. Good Packaging
All products are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
5. CE Certification
1. What's the minimum order quantity?
One set at present.
2. What kind of payment term do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal.
3. How will you delivery these goods?
It will be decided according to your quantity. Normally we will choose International Express, Air and sea.
4. How will package glass equipment?
We package these glass equipment in good and non fumigation standard plywood.
5. Can you accept OEM terms?
Sure.
