Electric Heating Mantle for Lab using

Name: Electric Heating Mantle for Lab using
Brand: ZZKD
Price: USD $1 - 600 / Set

FOB Price

USD $1 - $600 / Set

1 Set(Min.Order)

Product Details

Brand Name:

ZZKD

Model Number:

ZNHW-II

Place of Origin:

Henan, China

Electric Heating Mantle for Lab using

Features of electric heating mantle

(1) Shell made of one-time molding plastics, anti-corrosive and fine insulation.

(2) PID intelligent operation control and burnout protection, more accurate and convenient.

(3) Can heat standard or nonstandard reaction bulbs from 50ml to 1000ml.

(4) Heating mantle, big heating area, balance in heating and heating up fast.

(5) Digital display of temperature, more clear.

Technical parameter of electric heating mantle

Model	ZNHW-II
Power Supply	220V /50Hz
Heating power(W)	450
Heating temperature (℃)	≤380
Temperature accuracy (℃)	±1
Temperature control device	Digital precision control
Boiling	2000 ml water, 7-10 minutes
Furnace wire	Cr20Ni80
Insulating layer	Alkali-free fiberglass
Insulation coefficient (mega)	When the heating mantle relative humidity≤35%, its insulation coefficient ≥500 megabytes.
Thermal insulation layer	Adopt environmentally friendly vacuum forming aluminum silicate cotton moisturizing body
Inner sleeve diameter (mm)	180
Inner sleeve depth (mm)	105
Shell diameter (mm)	270
Shell height (mm)	190

Pictures of electric heating mantle
