(KD) Factory Price Freeze Dryer
Features
1. Accord with international standards of Green environmental friendly;
2. 7" True~color Touch Screen, Chinese English Bilingual Interface, display drying curve and history curve;
3. U disk Can storage lyophilized data;
4. Upload software can print curve;
5. Embedded circuit design, 128 M FLASH, can save dozen times Lyophilized data;
6. Large opening trap, no coil inside, with samples pre-freeze function.
7. Imported refrigeration compressor, low noise.
8. Cold trap and control panel were made by stainless steel, corrosion-resistant, easy to clean.
9. Transparent Bell type drying room, secure and ocular.
Technical data
18ND | Ordinary | Top-Press | Ordinary Multi-Manifolds | Top-Press Multi-Manifolds |
No-load Temperature(℃) | <-56 | |||
Freeze Area(m2) | 0.18 | 0.09 | 0.18 | 0.09 |
Plate Load Capacity(L) | 2 | 1 | 2 | 1 |
Ability to Capture Water(Kg) | 6 | |||
Vacuum Degree(Pa) | <10 | |||
Machine Dimension (W*D*H)mm | 700*560*(960+450) | |||
Sample Tray Size(mm) | 4×Φ240 | Ø 3×200 | 4×Φ240 | Ø 3×200 |
Power(W) | 1300 | |||
Power Supply | 110V/60HZ or 220V/50HZ | |||
Interlayer spacing(mm) | 70 | |||
Cold trap size(mm) | Ø270×410 | |||
The number of schering bottles
| Ø22: 360 | Ø22: 270 | Ø22: 360 | Ø22: 270 |
Ø16: 740 | Ø16: 560 | Ø16: 740 | Ø16: 560 | |
Ø12: 1320 | Ø12: 990 | Ø12: 1320 | Ø12: 990 | |
N. W. / G. W | 130KG/145KG | 135KG/150KG | 145KG/160KG | 150KG/165KG |
Packaging
-Export wooden or carton packing.
-Both neutral and customized packaging can be available.
Shipping
-We can ship the goods to you per the below shipping methods and you can choose the appropriate one based on your timeline and budget. Also you can definitely choose to use your own shipping agent.
1. ZZKD Instruments provides ONE YEAR WARRANTY for the products described here.
2. The warranty covers part and manufacturing defects. In the case of a part or manufacturing defect, the device shall be repaired or replaced free of charge under the terms of the warranty.
3. Beyond the warranty period, product problems can also be solved by our company, but charge component cost and maintenance cost properly.
4. ZZKD Instruments shall not assume liability for any damages incurred as a result of improper handling.
5. If you encounter problems when using our products, please contact us by telephone or e-mail, we will be ready to provide consulting, maintenance and other services immediately.
Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd.
Our company always adheres to the "quality casting brand, professional achieves service"
business philosophy, and the main product is rotary evaporator, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), low temperature cooling fluid circulating pump(cooling chiller), vacuum drying oven, blast drying oven, high-pressure reaction kettle, microwave chemical reactor, freeze dryer(lyophilizer), water/oil bath, magnetic heating stirrer, hydrothermal synthesis reactor, heating mantle, lift jack, etc.
1. What's the minimum order quantity?
One set at present.
2. What kind of payment term do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal.
3. How will you delivery these goods?
It will be decided according to your quantity. Normally we will choose International Express, Air and sea.
4. How will package glass equipment?
We package these glass equipment in good and non fumigation standard plywood.
5. Can you accept OEM terms?
Sure.
