Specifications
1.Safety2.Good quality
3.Higher oil output
4.Environmental protection
5.Transform tyre,plastic and rubber into crude oi
1)Working process
Firstly, put the raw material into furnace,then seal the feed inlet system.
Secondly, burn the fuel material (coal,or wood,or natural gas, oil ) in the combustion system, the reactor will slowly heat ,when the temperature reaches around 250 degree Celsius,it will produce oil gas, oil gas will be processed by our technology ,then goes to the cooling system to cold liquid oil.the gas which can not be liquid under normal pressure ,which will be designed to back to combustion system to instead the fuel material to burn the reactor, which can save energy very much .After finishing oil produce ,the temperature of reactor will be down, at the same time ,carbon black will be discharged automatically.
Lastly,when the temperature falls to 100 degree Celsius,worker could open the door of reactor to discharge of steel wire .Then can start another batch working.
2)Overview of pyrolysis plant
The whole pyrolysis system is composed by 13 parts, which are reactor, transmission device, catalytic chamber, cooling tube, heavy tank, oilwater separator, condenser, light oil tank, safety device, vacuum system, dedusting system, draft fan and chimney.
3)Information of outputs
As a result of pyrolysis of wastage tyres one obtains,
FUEL OIL (40% to 45%),CARBON BLACK (30% t0 35%),STEEL WIRE (10% to 15%)
4) Purposes of the Outputs
Fuel Oil: Oil from this plant can be used as industrial fuel for burning
Crude Carbon Black: Crude Carbon Black form this plant is crude, and it can be sold to the brick factory as internal combustion or to the factory needing it as raw materials, such as tyre, shoe, cable and sealant company.
Steel Wire: It can be sold to the iron and steel company directly
5)Profit analysis
Take waste tire oil refining equipment processing 10 tons for example
No. |
Item |
Cost of Per Batch |
1 |
10 tons of waste tires |
10T×1500RMB/T=15,000RMB |
2 |
0.4 tons of coal |
0.4T×800RMB/T=320RMB |
3 |
Water and electricity |
200×1.00RMB=200RMB |
4 |
Workers |
4×100RMB=400RMB |
5 |
Total Cost |
15,920RMB |
NO. |
Item |
Income |
1 |
Crude Oil |
10T×45%×4,500RMB=20,250RMB |
2 |
Carbon Black |
10T×35%×520RMB=1,820RMB |
3 |
Steel Wire |
10T×13%×2200RMB=2,860RMB |
4 |
Gross Profit |
24,930RMB |
5 |
Daily Net Profit |
24,930RMB-15,920RMB=9,010RMB |
6 |
Monthly Net Profit |
9,010RMB×25=225,250RMB |
7 |
Yearly Net Profit |
225,250RMB×10=2,252,500RMB |
|
|
