Help CenterZH-800C Multifunction Automatic Carton Box Gluefolder Pasting Machine
Related Products
-
High Speed Automatic Folder Gluer With PreFoldingNegotiableMOQ: 1 Set -
Automatic Roll Feeding Food Paper Bag Making MachineNegotiableMOQ: 1 Set
-
High Precision Automatic Western Envelope Forming MachineNegotiableMOQ: 1 Set
-
Automatic Small Mini Paper Box Folding Gluer MachineNegotiableMOQ: 1 Set
-
Small Envelope Bag Folding Gluing MachineNegotiableMOQ: 1 Set
The high speed sticking the box machine to use the integrated enclosed type glue water box automatically, causes the glue water not not easily to evaporate, moreover the glue water box position may not move willfully in the engine off situation. Sticks when the box debugging will only use a handwheel to move row of, above tool holder and so on the part synchronization migrations reaches one's goal instantly. Behind the pressure delivers around to be possible to adjust, to the liquor box, the long box is specially convenient. Causes the equipment the structure to be more perfect, to be reasonable, the applicable scope is more widespread, the debugging time reduces enormously, the operating speed distinct enhancement, after the improvement sticks the box machine to be possible and the import machine compares favorably with with Taiwan machine.
FEATURES
1. Line speed:0-220m/min continuous adjustment.
2. Usage paper:210-600g/ Paperboard
3. The box forming: Either sides folds, the both sides prefold and either side glue.
4. Paper feeding: Automatic feeding
5. Binder: Dissolve the type.
6. Electric: Single-phase AC220V 2.2KW
7. Weight:1800kg
8. Dimension:5800×900×1300(mm)
9. The counting range:0999999(full-automatic)
Main Technical Parameters
