Automatic Paper Plate Dish Forming Machine

Specifications

1.TWO independent work stations
2.Make 4-12inch paper dish
3.15-25pcs/staion/min.
4.With 2 free molds

Characteristics



1.ZDJ-300 paper plate forming machine is developed and designed as the requirement of market.



2.It is pneumatic type automatic paper dish forming machine with owned unique illtellent property right, which has functions as automatic paper feeding, forming, dish ejecting, temperature constant controlling, automatic counting, fast working speed, safe operation and  easy maintenance, etc.



3.This machine has two working stations, two molds installed in the machine, you can produce two sizes paper plates at the same time or let the two molds the same to get double speed.



Technical specifications



Dish size	4-12inch
Raw material	Cardboard, Compound paper or ivory board
Suitable paper weight	180-600gsm (Recommend 350-450gsm)
Air flow	1m3/min
Electrical Supply	220V 50Hz
Total power	4.2KW
Rated Productivity	15-25pcs/min (one working position)*2
Weight	300kg
Air pressure	>0.6mpa
Appearance size	1300*1000*1750mm
