SHENGDA SD-9878 40T Full Automatic Computer Numerical Control High Efficiency Push Plate Feeding Cutting Press Machine
SHENGDA SD-9878 40T Full Automatic Computer Numerical Control High Efficiency Push Plate Feeding Cutting Press Machine
SHENGDA SD-9878 40T Full Automatic Computer Numerical Control High Efficiency Push Plate Feeding Cutting Press Machine
1. This machine is widely suitable for cutting a variety of non-metal material by die cutter. For example: Plastic, EPE packaging, Rubber, Printing and Other industries.
2. Computer control: The cutting head die punching automatically. Automatically set cutting times, high accuracy, positioning accuracy reach to 0.2mm so as to save material, impreve efficiency, reduce labor intensity.
3. Computer control cooperates with servo motor to drive the puch head rotating untrammeled. The head can be set to any angle. The punch head can be set to cut with different angles in the case of continuous work every time. So that it can save material most maximized.
4. Computer control cooperates with servo motor to drive the threaded rod, which controlling the latest movement of this head, which can adjust the punch head position accurately.
5. Computer control cooperates with servo motor. Meanwhile, the cylinder press material to drive the threaded rod for controlling the feeding time, feeding distance, and feeding speed.
6. The machine adopt four column-oriented system, double crank balanced, hydraulic drive, ensuring speed and precision of cutting die machine.
7. The self-lubricating system in the central to ensure the life and accuracy of the machine.
8. Special specifications can be specially designed and manufactured according to customer requirements.
|
|
|
| |
