Woodworking Multi Drill Multi Drilling Machine

Name: Woodworking Multi Drill Multi Drilling Machine
Brand: HAIYONG
SKU: 141508766
Availability: InStock

Qingdao Haiyong Machinery Manufacturing Co., Ltd.

US$ 1,000 - 6,000 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Spindle Speed:

2840r/min

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Spindle Speed 2840r/min

Place of Origin Shandong, China

Brand Name HAIYONG

Model Number MZ73213

Power(W) 4500

Weight 1260KKG

Dimension(L*W*H) 2500X2600X1600MM

Certification ISO9001 BV

After-sales Service Provided Overseas service center available

Specifications

this multi drilling machine is three-randed carpenter drilling machine.max diameter of holes is 35mm.

Basic feature of the multi drilling machine

1 the working range of the drill is very large. All the drill can be jointed quickly.it is very quick and convenient

2 The drilling depth and distance are controlled by sensor and linear guide, so it can locate quickly and accurately

3 Using famous brand touched screen and adopting PLC control system,the machine is powerful and of lower failure rates,

so it is durable

4 Selection of high quality steel parts, and it is never deformed by high-strength heat treatment.

5 Equipped with digital calculator to measure sizes which enhances the work efficiency.

Technical specifications of multi drilling machine

Max diameter of holes	35mm
Depth of drilled holes	0-60mm
The number of spindles	63
Centerdistance betwween spindles	32mm
Rotation of spindle	2840r/miin
Total motor power	4500w
Air pressure	0.5-0.8mpa
Overall size	2500x2600x1600mm
weight	1260kg
