Help CenterThree Ranged Carpenter Drilling Machine
Related Products
Specifications
this drilling machine is working for wood based panel. the max depth of drilled holes is 60mm.Basic feature of this machine
1 the working range of the drill is very large. All the drill can be jointed quickly.it is very quick and convenient
2 The drilling depth and distance are controlled by sensor and linear guide, so it can locate quickly and accurately
3 Using famous brand touched screen and adopting PLC control system,the machine is powerful and of lower failure rates, so it is durable
4 Selection of high quality steel parts, and it is never deformed by high-strength heat treatment.
5 Equipped with digital calculator to measure sizes which enhances the work efficiency.
Technical specifications
Max diameter of holes |
35mm |
Depth of drilled holes |
0-60mm |
The number of spindles |
63 |
Centerdistance betwween spindles |
32mm |
Rotation of spindle |
2840r/miin |
Total motor power |
4500w |
Air pressure |
0.5-0.8mpa |
Overall size |
2500x2600x1600mm |
weight |
1260kg |
